Gate marks are a line where a pan was broken from its mould. They are found on all cast iron pans and refer to the area where the piece separates from the pattern when it is made. In the 19th century, advancements in casting technology led to the technique of side gating, which moved the gate away from the bottom of the pan. Bottom gating was still used on large pieces like cauldrons, where side gating was impractical, and by smaller foundries. Bottom gating also continued to be used by individuals or small foundries making copies of other pans. While gate marks are not exclusive to antique cast iron pans, they can indicate that the pan is from the late 18th or 19th century.
What You'll Learn
- Gate marks are a by-product of older iron casting methods
- Bottom gating was replaced by side gating in the late 1800s
- Bottom gating continued to be used for large pieces like cauldrons
- Bottom gating was also used by individuals or small foundries making copies
- Gate marks are the area where the piece separates from the pattern
Gate marks are a by-product of older iron casting methods
Prior to the adoption of side gating, the casting process was much simpler. Craftsmen would pack sand into a box, create a cavity in the desired shape, drill a hole, and pour molten iron into it. This traditional method, known as bottom gating, often left a noticeable mark on the bottom of the pan where the iron was poured into the mould.
While side gating offered improved aesthetics and convenience, it required more elaborate patterns with runners, multiple gates, and risers to ensure even filling of the mould. Companies like Wagner and Griswold, who entered the market during this transitional period, embraced side gating from the outset.
However, smaller foundries, particularly those producing large-format pieces like cauldrons, continued using bottom gating due to its practicality and simplicity. Additionally, individuals or small foundries creating copies of others' pieces also favoured the traditional method.
Today, gate marks are still present on modern pans, but they are typically found along the upper edge of the pan and are ground off as part of the finishing process, making them less noticeable compared to their vintage counterparts.
The presence of a bottom gate mark on a cast-iron pan often indicates production in the late 18th or 19th century. However, it's important to note that some foundries continued using bottom gating well into the 20th century, especially for larger pieces.
