When it comes to Ford Mustang C4 transmissions, it is possible to remove and replace the servo with the pan on. However, it is not a straightforward process. It involves dropping the pan and removing the valve body to access the servo. After removing the servo cover, the servo can be taken out, and during this process, a thing may fall out of the inside of the transmission. This part goes between the servo shaft and the band and must be put back in place during reinstallation. While it is possible to perform this procedure with the pan on, it is important to carefully follow the steps to avoid any issues.
Explore related products
What You'll Learn
Drop the pan and valve body
Dropping the pan and valve body of a C4 servo is a straightforward process. It is often done to access the drums and bands to check the adjusters and perform an air check on the pressure ports.
First, remove the bolts and pry off the case. When doing this, be careful of any parts falling off or coming apart. Once the case is off, remove the servo cover, followed by the servo. A "thing" will fall out of the inside of the transmission, which goes between the servo shaft and the band. Make sure to put it back in place when reinstalling the servo.
Next, you will need to remove the valve body. Before doing so, it is recommended to check the operation of the kick-down valve by pushing the plunger to ensure it moves freely and returns fully after cleaning. If any valves are sticking or frozen, they should be removed and the valve casting cleaned carefully.
When removing the valve body, ensure the two adjusters are still in place. Once the valve body is off, perform an air check on the pressure ports on the underside.
Finally, install the new servo, followed by the valve body, oil pan, and servo cover.
