The Elecraft PX3 Panadapter is a portable, high-performance panadapter for the KX3 Transceiver. It allows you to see the current band in real time with spans of 2-200 kHz. The PX3 features CW/RTTY/PSK text display, multi-pass signal averaging to pull out weak signals, peak detection, and adjustable reference levels. Its small size and weight make it ideal for travel or field use. The PX3 can be powered from an external source by connecting the two power cables together. While the PX3 has many features, it is unclear whether it can display 2 meters specifically.
Explore related products
What You'll Learn
The PX3's small size and weight make it ideal for travel
The PX3 Panadapter is a portable, high-performance device that is ideal for travel due to its small size and lightweight design. Weighing just 13 oz (0.37 kg), the PX3 is easy to carry and transport, making it a convenient choice for those on the move. Its compact enclosure size of 5.4 x 3.4 x 1.7" (13.7 x 8.6 x 4.3 cm) ensures that it takes up minimal space in your luggage or bag.
The PX3's lightweight and compact design make it a versatile tool that can be easily deployed in a variety of environments. Whether you're an amateur radio enthusiast or a professional technician, the PX3's portability allows you to monitor and analyse signals in remote locations with ease. Its small size and weight make it ideal for outdoor use, field work, or any situation where mobility is a priority.
The PX3's lightweight design does not compromise its performance. On the contrary, the PX3 offers a wide range of features and capabilities that enhance its functionality. With a frequency span of up to 200 kHz, the PX3 provides a much wider range of signal visibility compared to PC-based panadapters. Its high-performance analog-to-digital converter (ADC) results in a low noise floor, ensuring clear and accurate signal processing.
Additionally, the PX3's low current drain of typically 140 mA @ 13.8 V contributes to its energy efficiency. This, coupled with its small size, makes the PX3 a power-efficient and portable solution for your signal analysis needs. The PX3 can be powered from an external source, providing flexibility and convenience when travelling or working in locations without direct access to power sources.
Overall, the PX3's small size and weight make it an ideal companion for those who require signal analysis capabilities on the go. Its portability, coupled with its high performance and energy efficiency, ensure that you have a powerful and versatile tool at your disposal, no matter where your travels take you.
Magnetic Attraction: Are All Eyeshadow Pans Magnetically Charged?
You may want to see also
Explore related products
The PX3 can display spans of up to 200 kHz
The Elecraft PX3 is a high-performance panadapter for the KX3 transceiver. It allows users to see the current band in real time, with spans of 2-200 kHz. This is a much wider range than what can normally be heard. The PX3's small size and weight make it ideal for travel or field use. It is also very tightly integrated with the KX3, making it very convenient to use.
The PX3 has a wide supply voltage range of 8-15 V and a low current drain of typically 140 mA @ 13.8 V. It includes a comprehensive manual and is available factory assembled or as a modular, no-soldering kit. The PX3 features CW/RTTY/PSK text display, multi-pass signal averaging to pull out weak signals, peak detection to show total activity on the band, adjustable reference level, and amplitude range scaling. There is also a full set of programmable switches to access often-used settings.
The PX3 adds a visual dimension to signal hunting, with fast, real-time spectrum and waterfall displays of band activity. It makes use of baseband RX I/Q signals from the KX3, which are sampled by an analog-to-digital converter (ADC) and then mathematically processed to create the spectral and waterfall displays. The PX3's ADC is very high performance, resulting in a low noise floor, and the supplied cables are short to minimize noise pickup.
The PX3 can be powered from an external source by connecting the power cables of the PX3 and KX3 together. This allows you to monitor battery voltage directly from the KX3. The PX3 can also be connected to a radio with I/Q signals available to see the RF spectrum. However, some features of the PX3 may not be available when connected in this way.
Pan and Crop in After Effects: The Ultimate Guide
You may want to see also
Explore related products
The PX3 is very tightly integrated with the KX3
The PX3 is a high-performance panadapter for the KX3 transceiver. It allows you to see the current band in real time, with spans of 2-200 kHz. The PX3 is very tightly integrated with the KX3, making it very convenient to use. It utilizes the KX3's serial control port and RX I/Q signals. The panadapter tracks the KX3's VFO frequency and filter settings via on-screen cursors.
The PX3 has a wide range of features, including CW/RTTY/PSK text display, multi-pass signal averaging to pull out weak signals, peak detection to show total activity on the band, and adjustable reference level. It also has a full set of programmable switches to access often-used settings. The PX3 is shipped with its own power cable, and it has a wide supply voltage range (8-15 V) and low current drain.
The PX3's companion product, the P3, uses Intermediate Frequencies for input, which is supplied by the K3. Both units are optimized for operation with their respective radios, resulting in full integration for both. The PX3 is also designed to work seamlessly with the KX3's high-performance KXPA100 home/mobile amplifier. This amplifier can be used to add more power to the KX3 when it is being used at home.
The PX3's small size and weight make it ideal for travel or field use. It adds a visual dimension to signal hunting, with fast, real-time spectrum and waterfall displays of band activity. The PX3 is a powerful tool for anyone using the KX3 transceiver, providing a wide range of features and functionality that enhance the user experience.
The Magic of Deglazing: Transforming Your Pan with Flavor
You may want to see also
Explore related products
The PX3 has a wide supply voltage range (8-15 V)
The PX3 Panadapter is a portable, high-performance panadapter for the KX3 Transceiver. It allows you to see the current band in real-time with spans of 2-200 kHz. The PX3 has a wide supply voltage range of 8-15 V and a low current drain of 140 mA @ 13.8 V. This means that it can be powered by a variety of external sources, as it has a wide voltage range. The PX3 comes with its own power cable, but it cannot be powered by the KX3's batteries. To power the PX3 from an external source, you can connect the two power cables together. This allows you to monitor battery voltage directly from the KX3.
The PX3's wide voltage range makes it a versatile device that can be powered by a variety of external sources. This is especially useful when travelling or using the device in the field. The PX3's small size and weight make it ideal for travel or field use. Its wide voltage range also provides flexibility in terms of power options, allowing users to choose the most convenient or readily available power source.
The PX3 has many powerful signal processing features, including multi-line CW/data text send/receive, which works great with an attached USB keyboard. It also has a very wide dynamic range and frequency span of up to 200 kHz, offering better performance than most PC sound cards. The PX3 is fully integrated with the Elecraft KX3, utilizing its serial control port and RX I/Q signals. It tracks the KX3's VFO frequency and filter settings via on-screen cursors, allowing users to point and click on signals by rotating and tapping the PX3's SELECT knob.
The PX3's wide voltage range also ensures compatibility with a wide range of power sources, making it accessible to users with different power configurations. The device's low current drain also contributes to its efficiency and makes it a cost-effective option. The PX3's comprehensive manual provides detailed information on its power requirements and usage, making it easy for users to set up and operate the device.
Overall, the PX3's wide supply voltage range of 8-15 V is a significant advantage, providing versatility, flexibility, and compatibility with various power sources. This feature, along with its small size and weight, makes the PX3 a convenient and powerful tool for signal hunting and spectrum analysis.
Ceramic Pan: What's the Deal?
You may want to see also
Explore related products
The PX3 can be used to monitor battery voltage
The PX3 Panadapter is a portable, high-performance device that can be used with the KX3 Transceiver. It offers a visual dimension to signal hunting, with real-time spectrum and waterfall displays of band activity. The PX3 has a wide supply voltage range of 8-15 volts and a low current drain of typically 140 mA at 13.8 volts.
The PX3's battery monitoring capability is a valuable feature, especially when used in conjunction with the KX3 transceiver. By tracking battery voltage, users can make informed decisions about power management and ensure their devices are adequately charged for field use. This capability is essential for maintaining consistent performance and avoiding interruptions due to power-related issues.
Additionally, the PX3's battery voltage monitoring can help prevent potential damage caused by deep discharge. Deep discharge occurs when a battery is excessively drained, leading to reduced performance and lifespan. By monitoring battery voltage, users can take proactive measures, such as recharging the battery before it reaches a critically low level, thereby protecting their equipment and maintaining optimal performance.
In conclusion, the PX3's ability to monitor battery voltage is a significant advantage, ensuring uninterrupted operation and contributing to the overall reliability and longevity of the user's equipment. This feature exemplifies the PX3's thoughtful design and consideration for practical, real-world applications.
Use Dryer Sheets to Clean Your Burnt Pans
You may want to see also
Frequently asked questions
A panadapter, also known as a spectrum scope, is a device with a 2-dimensional display showing frequency on its X-axis and signal amplitude on its Y-axis. This allows you to see signals on a given band, over a much wider range than you can normally only hear them.
PX3 features include CW/RTTY/PSK text display, multi-pass signal averaging to pull out weak signals, peak detection to show total activity on the band, adjustable reference level, and amplitude range scaling.
The PX3 has a wide supply voltage range (8-15 V) and low current drain (typ. 140 mA @ 13.8 V).
Yes, you can if your radio has I/Q signals available, you can connect the PX3 to it to see the RF spectrum with it. Due to the highly integrated nature of the KX3/PX3 combination, there will be some features of the PX3 not available when connected in this way.
The Elecraft PX3 is priced at $700.
