Building a concrete shower pan over a wood subfloor is a complex process that requires careful planning and execution to ensure a functional, durable, and visually appealing shower. A shower pan is the sloped base of a walk-in shower that forms the shower floor, and it is crucial to have a solid subfloor and properly installed drain base before beginning construction. The process involves preparing the subfloor, installing a pre-slope, adding a liner, creating a mud bed, and finishing with a tile surface. Proper waterproofing is essential to prevent water permeation and mold outbreaks. While it is possible to build a concrete shower pan over a wood subfloor, it is important to follow the necessary steps and guidelines for a successful installation.
| Characteristics | Values |
|---|---|
| Materials | Concrete, cement, plywood, tile, mortar, waterproofing membrane, galvanized wire mesh, stucco wire, screws, adhesive, gravel, tile spacers, plastic sheet |
| Steps | Clear and prepare the subfloor, install drain base, apply waterproofing membrane, attach cement board, apply thin-set mortar, tile the shower pan, install pre-slope, install liner, install mud bed and curb, install water barrier, pour concrete |
| Tips | Ensure proper preparation and waterproofing, create a solid foundation, use self-leveling compound if subfloor is uneven, slope the floor to ensure water is directed to the drain, cover the drain hole if no drain plug is available, use Oatey's Perfect Slope for ease of installation |
Explore related products
What You'll Learn
Prepare the subfloor
Preparing the subfloor is a crucial step in ensuring the durability and functionality of your shower pan. Here are the detailed steps to prepare the subfloor for a concrete shower pan installation over a wood subfloor:
First, clear the area by removing any debris, old tiles, or flooring materials from the plywood floor. Check the condition of the wood subfloor to ensure it is stable, free of rot or damage, and strong enough to support the weight of the concrete shower pan. Make sure to consult your local building code and relevant guidelines, such as the Tile Council of North America (TCNA) Handbook and ANSI108.1, for specific requirements and recommendations.
Next, mark the location of the drain by measuring and indicating its position on the wood subfloor, considering the desired shower size and accessibility. Use a utility knife to cut a hole in the plywood floor according to the drain specifications. Install the drain base by following the manufacturer's instructions, placing it over the hole, and screwing it securely onto the wood subfloor.
Apply a waterproofing membrane over the plywood floor to ensure a completely watertight shower pan. Measure and cut the membrane to size, leaving extra material to cover the walls. Spread a layer of thin-set mortar onto the plywood floor within the boundaries of the membrane using a notched trowel.
To create a curb for your shower pan, stack and fasten 2x4s sequentially to the subfloor. Screw the bottom 2x4 to the subfloor and then attach the second 2x4 to the fastened first 2x4, repeating this process to achieve the desired curb height. You can then attach metal mesh or stucco wire to the lumber curb to help hold the mortar, which will be applied with the first mortar layer.
Finally, check the levelness of the subfloor to ensure it is completely flat and level. If the subfloor is not level, apply a self-leveling compound, following the manufacturer's instructions, to create an even surface. Allow the compound to cure, and then test-fit the shower drain flange to ensure it fits flush with the shower base.
