The evaporator WR84X10038 is a common component found in many refrigerators, responsible for absorbing heat and cooling the interior. A frequent question among homeowners and technicians is whether this specific evaporator model features only one pipe in its design. Understanding the configuration of the evaporator is crucial for maintenance, troubleshooting, and ensuring optimal performance of the refrigerator. Typically, evaporators may have one or more pipes depending on the system’s design, but the WR84X10038 is known for its straightforward, single-pipe setup, which simplifies installation and reduces potential points of failure. However, it’s always advisable to consult the manufacturer’s specifications or a professional to confirm the exact configuration for your specific appliance.
| Characteristics | Values |
|---|---|
| Number of Pipes | Typically, the evaporator WR84X10038 has two pipes: one for the refrigerant inlet and one for the outlet. |
| Compatibility | Designed for specific GE refrigerator models. |
| Function | Facilitates heat exchange to cool the refrigerator compartment. |
| Material | Usually made of aluminum or copper for efficient heat transfer. |
| Installation | Requires professional installation due to refrigerant handling. |
| Part Type | Evaporator assembly, part of the refrigeration system. |
| Common Issue | May need replacement if clogged, damaged, or inefficient. |
| Availability | Available through GE parts suppliers or authorized dealers. |
| Price Range | Typically ranges from $100 to $200, depending on the supplier. |
| Warranty | Often covered under manufacturer warranty for a limited period. |
