Oil Pan Performance: Ls6 Oil Starvation Solution?

The LS6 oil pan is an effective solution to the problem of oil starvation in high-performance engines. Oil starvation occurs when oil doesn't flow into vital engine components, which can lead to catastrophic engine failure. The LS6 oil pan is designed to improve oil flow and control, ensuring that the engine receives the lubrication it needs during high-speed cornering and acceleration. It features a complex four-stage design, including a windage tray, oil deflector, and baffles that direct oil back to the sump. This prevents the oil from sloshing around and starving the engine of lubrication. The LS6 oil pan is also structurally integrated into the engine block, adding strength and reducing the risk of leaks. Overall, the LS6 oil pan is a reliable solution for preventing oil starvation and improving engine performance.

LS6 oil pan design

The LS6 oil pan is a complex four-stage design, the closest thing to a dry sump setup in a production car. It features a full-length windage tray, integral crank scraper, oil deflector, and slotted directed drainage. The stamped oil pan baffle is stepped and gated, directing oil straight to the sump. The LS6 oil pan also has side "wing" compartments for extra capacity in competition and a stepped and gated sump with dams and windows to prevent the deep sump from being uncovered.

The LS6 oil pan is designed to address the issue of oil starvation, which occurs when oil doesn't flow into vital engine components. Oil starvation can cause catastrophic engine failure. The LS6 oil pan's complex design helps to ensure proper oil management, keeping the end of the pickup tube submerged in oil. This prevents oil starvation and protects the engine.

The LS6 oil pan is also a structural component of the engine block, which makes it less prone to failure or leaking than aftermarket sheet metal pans. It is made of cast aluminum, which is considered a structural member of the engine block. This construction adds strength and security to the oil pan, further reducing the risk of oil starvation.

Overall, the LS6 oil pan is a well-engineered solution to the problem of oil starvation, providing effective oil control and protection for high-performance engines.

Oil starvation causes

Oil starvation can be caused by a variety of factors, and it is a common issue that can lead to severe consequences. Here are some key causes of oil starvation:

• Inadequate lubrication: This is one of the most common reasons for failure. It can be caused by low oil levels, using the wrong type or grade of oil, or oil contamination.
• Dry starts: When an engine is turned off, oil drains down to the oil pan. On restart, critical frictional zones are momentarily starved of lubrication, leading to accelerated wear.
• Cold starts: During cold starts, oil movement in the engine can be slower, inducing air into the flow line due to cold-temperature suction-line conditions.
• Low oil pressure: This can be caused by worn bearings, pump wear, sludge buildup, or extreme cold temperatures. Oil pressure is crucial in ensuring oil reaches the zones requiring lubrication.
• Dribbling injectors: Fuel injector problems can wash oil off cylinder walls, impairing lubrication between the piston, rings, and cylinder wall.
• Clogged components: Sludge and contaminants can restrict oil flow by clogging spray nozzles, orifices, oil groove paths, and oil return lines.
• Aeration and foam: Air contamination in the oil sump can dampen oil movement and impair the performance of oil feed devices, reducing the volume of oil supplied to critical components.
• Improper oil management: Oil starvation can occur if there is not enough oil volume in the sump, or if the oil drain back is slow, preventing the oil from returning to the sump quickly enough.
• Oil pump issues: Oil pump priming can be challenging, especially with newer engines that have longer pickup tubes and differently positioned oil pumps. Improper modifications to the oil pickup can also lead to aeration and cavitation issues.
• Design flaws: In some cases, oil starvation may be due to design flaws in the oil pan or pump. For example, the original LS7 oil pan design exposed the end of the pickup tube during high-speed cornering, leading to oil starvation.

It is important to identify and address these causes to prevent oil starvation and ensure the optimal performance and longevity of engines and machinery.

Oil starvation prevention

Oil starvation is a serious issue that can cause catastrophic engine failure. It occurs when oil doesn't flow into vital engine components. This can happen due to a failure of the oil drain back or oil management within the engine.

The LS engine family is prone to oil starvation, especially at high Gs and high RPMs where oil aeration and windage are more prevalent. The deep skirt factory block used in the LS1/LS2/LS3/LS6 engines can make it difficult for oil to return through the use of a traditional oil pan.

To prevent oil starvation, proper oil pan baffling is critical. Baffles help to keep oil around the pickup tube and improve oil control. Trap door baffles are particularly effective, as they completely enclose the oil pump pickup. Drain-back slots in the baffle plate also help to accelerate the return of oil to the bottom of the sump while preventing oil slosh and reducing oil consumption.

Another way to prevent oil starvation is to use a dry sump oiling system, which removes oil from the pan and stores it externally, ensuring a constant supply of oil to the engine. Aftermarket solutions are available from companies like Armstrong Race Engineering, Moroso, Canton Racing Products, and Dailey Engineering.

In addition to proper oil pan baffling and dry sump systems, other ways to prevent oil starvation include:

• Using a proper oil management system to ensure enough oil volume in the sump to keep the end of the pickup tube submerged in oil.
• Improving the oil drain back to the sump by adding dedicated oil passageways and windage trays.
• Running the correct amount of oil. It is important to follow the manufacturer's recommendations for oil capacity and not run low on oil.
• Using an accusump, which uses compressed air and a spring to force oil into the engine when the oil pressure drops.
• Extending the sides of the oil pan and adding doors to control oil sloshing during turns.
• Drilling holes in the oil pan walls to slow the movement of oil without stopping it completely.
• Using a windage tray or screen to run the full length of the pan, pulling oil away from the rotating assembly.
• Using the correct oil pump for your application. The LS-style pumps are driven at full engine speed from the crankshaft, while older camshaft-driven pumps run at half engine speed.
• Adjusting the oil pressure with a pressure relief valve to postpone the onset of cavitation.

By implementing these strategies and using the right oil pan and pump for your specific application, you can effectively prevent oil starvation and keep your engine running smoothly.

Oil starvation solutions

Oil starvation is typically a failure of the oil drain back or oil management within the engine. It can be caused by a low engine oil level in the sump, a bent or kinked oil feed pipe, carbon deposits blocking the oil feed pipe, blockages caused by using silicone when fitting the oil inlet gasket, an incorrect oil gasket restricting oil supply, a blocked, damaged or poor-quality oil filter, or not priming the replacement turbo with oil during fitting and start-up.

To prevent oil starvation, it is recommended that you:

• Ensure you have the correct oil level in the sump.
• Do not use silicone on oil gaskets or sumps as it can become detached and block oil passages.
• Clean or replace oil inlet pipes to eliminate any carbon deposits or sludge that could restrict oil flow to the bearings.
• Check the oil pressure and oil supply to the turbo.
• Always use high-quality fresh oil and new oil filters when fitting a new turbocharger.
• Always prime a new turbo.

Other solutions to prevent oil starvation include:

• Using a dry sump setup.
• Using a dedicated oil pan, such as the LS6 oil pan, which has improved oil baffles to help eliminate oil starvation problems.
• Adding additional holes to the baffle to aid in oil drain back.
• Extending the sides of the oil pan and attaching doors to control oil sloshing during turns.
• Drilling a series of holes in the walls of the oil pan to slow the oil movement without stopping it completely.
• Installing a screen-type baffle over the front of the oil pan to allow for drain back and stripping.
• Using a trap door baffle in the factory baffle, running parallel to the sides of the pan rail as close to the pickup as possible.
• Using an Accusump, a device that uses compressed air and a spring to force oil into the engine when the oil pressure drops.
• Ensuring proper oil management so that there is enough oil volume in the sump to keep the end of the pickup tube submerged in oil.

Oil starvation and LS engine

Oil starvation is a serious issue that can lead to catastrophic engine failure. It occurs when oil doesn't flow into vital engine components. Engines use a closed-loop lubrication system, and oil starvation is typically caused by a failure of the oil drain back or oil management within the engine.

The LS engine, found in some GM vehicles, is particularly susceptible to oil starvation due to its design. To improve gas mileage, GM wanted to lower the hood and flatten the pan of the LS engine. This resulted in a very long pickup tube and an oil pump mounted high up in the engine. This combination of a high-mounted oil pump and a long pickup tube can lead to oil pump priming issues, as the oil has to travel a longer distance and can struggle to reach the pump, especially during cold starts.

To address oil starvation in the LS engine, several modifications and solutions have been proposed:

• Using an LS6 oil pan: The LS6 oil pan is considered an improvement over the LS1 pan and has better baffling to help with oil starvation. It has a shallow sump design and is a structural component of the engine. However, it has a reduced oil capacity.
• Installing an Accusump: An Accusump is a device that uses compressed air and a spring to force oil into the engine when the oil pressure drops. It acts as insurance against momentary loss of oil pressure.
• Adding a warning light: An additional oil pressure sender can be installed, along with a bright warning light, to alert the driver when oil pressure drops below a certain level. This can help prevent engine damage by allowing the driver to take immediate action.
• Upgrading to a dry sump system: A dry sump setup is a more expensive solution but offers a more comprehensive fix for oil starvation. It customizes the oil specifications and includes a large reservoir tank.

One company, Improved Racing, offers an LS2, LS6, and LSA Cadillac CTS-V Racing Oil Pan Baffle that is designed to prevent oil starvation. It features trap doors to keep oil around the pickup tube and improve oil control. This product is a direct bolt-in replacement for the stock steel baffle in the stock oil pan and has been track-proven to prevent oil starvation at up to 1.4 sustained lateral G's.
