Evaporator pans are used for a variety of purposes, from maple syrup production to air conditioning systems. In maple syrup production, evaporator pans are used to boil sap and create a density gradient that results in syrup. The pans have channels that allow sap to flow back and forth, with new sap constantly being added to maintain the gradient. In air conditioning systems, condensate drain pans are located in the furnace, directly under the evaporator coil, and are used to collect and drain excess condensation produced by the air conditioner.
| Characteristics | Values |
|---|---|
| Purpose | To measure evaporation, collect condensate, or evaporate sap to produce syrup |
| Evaporation Measurement | Used to determine the quantity of evaporation at a given location, taking into account climate elements like temperature, humidity, rainfall, drought dispersion, solar radiation, and wind |
| Types | Class A evaporation pan, Sunken Colorado Pan, Symon's Pan (or Symon's Tank), Condensate Drain Pan, Divided Pan, Maple Syrup Evaporator Pan |
| Shape and Size | Vary depending on type and usage; can be circular, square, or cylindrical with varying dimensions |
| Installation | Installed in a vertical or horizontal application, such as a garage or attic; may be automated with water level sensors and located near a weather station |
| Function | Holds water for evaporation measurements, collects condensate from HVAC systems to prevent water damage, or evaporates sap to produce syrup |
| Maintenance | Requires regular inspections and maintenance to prevent issues like water leaks, mould, and clogging |
| Performance | Evaporation rate varies based on climate conditions, with greater evaporation on hot, windy, dry, sunny days |
| Limitations | Evaporation measurements may be affected by heavy rainfall, and pans may overflow during significant rainfall events |
