A pan magazine is a type of ammunition storage and feeding device for firearms. It is characterised by its flat cylindrical shape and is mounted on top of the gun, using gravity to drop cartridges into the action. The cartridges in a pan magazine are arranged perpendicular to the axis of rotation, unlike drum magazines where they are arranged parallel. Pan magazines are most famously found in the Degtyaryov light machine gun and the American-180 submachine gun.
| Characteristics | Values |
|---|---|
| Magazine shape | Flat cylindrical |
| Magazine placement | Mounted on top of the gun |
| Cartridge arrangement | Perpendicular to the axis of rotation |
| Cartridge feeding | Gravity, ratchet and pawl mechanism, or unwinding circular spring |
| Examples of guns that use pan magazines | Lewis gun, Bren light machine gun, Degtyarev light machine gun, American-180 submachine gun, Bira gun, Howard Carr machine gun, AK family of assault rifles |
| Advantages | Allows soldiers to lie prone without exposing themselves, compact design, holds a large number of cartridges |
| Disadvantages | Prone to failure, no advantages over belt-fed designs |
Explore related products
What You'll Learn
Pan magazines are a type of drum magazine
A magazine is a device that stores and assists in the feeding of ammunition through the use of a mechanical (usually spring-loaded follower). It is an integral part of a firearm, either fixed internally or attached externally. Magazines come in many shapes and sizes, from integral tubular magazines on rifles and shotguns to detachable box magazines and drum magazines for automatic rifles and light machine guns.
The name "pan magazine" comes from their resemblance to a cooking pan, with a flat base and a circular wall around the edge. The cartridges are arranged like the spokes of a wheel, radiating out from the center. This design allows the magazine to hold a large number of cartridges without adding excessive height to the gun, which means that a soldier can lie prone on the ground without exposing themselves too much.
Pan magazines have fallen out of favor due to their proneness to failure and the fact that they offer no advantages over belt-fed designs. They are now considered a “weird" and rare magazine design.
