Ella Walter
The DJI Ronin-S is a single-handed gimbal that is lightweight, convenient, and packed with features. While it is easy to set up, balancing the gimbal can be tricky. The process involves adjusting the tilt axis, pan axis, and roll axis to ensure the camera stays still when rotated and tilted. The DJI Ronin app can be used to check the balance status and provide suggestions for improvement. This paragraph will explore the steps to balance the pan access of the Ronin-S and address common issues users face.
Explore related products
What You'll Learn
Adjust the pan arm to 45º
To adjust the pan arm to 45º, first tilt the Ronin-S at 45º. Adjust the pan arm so that the camera finds balance on the pan rotation. If the camera is top or bottom heavy, push the camera mounting plate arm backward or forward and toggle the lever to the lock position until the camera stays still when rotating the tilt axis by 45 degrees upwards or downwards.
The pan and tilt speed can be tapered while using the thumbstick, meaning more input equals more speed, and less input equals less speed. The rear gimbal motor is mounted at a 45-degree angle below the camera. This design allows the gimbal to do a 360-degree roll. The pan axis should be dead in the middle and should not favour the right or left.
In Mode 2, the thumb stick on the back of the Ronin-S controls pan and tilt, but in Mode 3, it controls tilt and roll. The Ronin-S design makes adjustments while balancing as simple as possible.
The Perfect Pan-Seared Mahi: A Quick Guide
You may want to see also
Explore related products
$150
Ensure the pan axis is centred
To ensure the pan axis is centred, you must adjust the position of the tilt arm until the camera stays still when you rotate the gimbal 90 degrees left and right. You can use the adjustment knob on the back of the tilt arm to slide the tilt arm left or right. Make sure that the pan axis is dead in the middle and doesn't favour the right or left.
To balance the pan axis, tighten the gimbal pan axis knob. Grab the grip and tilt it sideways. Then, check the gimbal's movement. If the gimbal is tilted to the right or left, push the pan axis arm forward or backward. Tighten the knob. If the camera can stay still, the Ronin-M is balanced.
Before adjusting the pan axis arm, hold the arm and lift it. To ensure the camera is facing vertically, rotate the lens. Check whether the camera is balanced. If the camera is top or bottom heavy, push the tilt axis arm up or down.
You can also adjust the tilt axis to 90 degrees and make the appropriate adjustments so that the lens can be positioned at 90 and 180 degrees without it moving.
Effective Ways to Clean an Oil Catch Pan
You may want to see also
Explore related products
Balance the roll axis
Balancing the roll axis of your Ronin M is a simple process, but it requires care and attention to detail. Here's a step-by-step guide to help you balance the roll axis effectively:
Firstly, hold the roll axis motor and check if the camera is balanced. If the left end of the roll axis is tilted downwards, it indicates that the camera is left-heavy. To correct this, push the roll axis arm to the right to adjust the balance.
Before making any adjustments, remember to hold the arm and lift it as shown in the user manual or tutorial videos. This will ensure that you are making the adjustments correctly and safely.
Now, tighten the roll axis knob to secure the adjustments you just made. Rotate the camera to the left or right by approximately 45 degrees. If the camera can remain still in this position, it indicates that the roll axis is successfully balanced.
Finally, grab the grip and tilt it sideways to check the gimbal's movement. A well-balanced roll axis will ensure that the gimbal does not tilt excessively to the right or left. If you notice any tilting, you can make fine adjustments by pushing the pan axis arm forward or backward and tightening the knob.
By following these steps and making the necessary adjustments, you should be able to achieve a balanced roll axis for your Ronin M, ensuring smooth and stable shots for your filming endeavours.
Antique Copper Coal Pan Valuation
You may want to see also
Explore related products
Use the DJI Ronin app to check balance status
The DJI Ronin app allows you to access and manage gimbal motor parameters, SmoothTrack, remote setup, and Ronin’s unique Axis Modes.
To check the balance status of your Ronin M, first, download the Ronin app and ensure Bluetooth is switched on. Then, start the app and follow the connection instructions. From the main screen, click Configuration, Motors, and then Auto Tune.
The Auto Tune function allows you to adjust motor parameters automatically based on the payload mounted. You can further adjust the Stiffness, Strength, Control, and Filter parameters accordingly.
Additionally, the Ronin app provides a live gimbal data feed, allowing you to access gimbal operation data in real time and diagnose the gimbal's status. This can help you identify any balance issues and make the necessary adjustments.
It is important to note that the Ronin app cannot be used for firmware updates. Firmware updates can be performed using the DJI Assistant software for Windows or Mac.
Pie Pan Volume: How Much?
You may want to see also
Explore related products
Adjust the tilt axis to 90º
To adjust the tilt axis to 90º, first ensure that your Ronin M is resting on a tuning stand. Then, rotate it along the pan axis by lifting one side of the handlebar. If the camera does not swing, the pan axis is balanced. If it does swing, you will need to adjust the position of the tilt arm until the camera stays still when you rotate the gimbal 90º left and right.
You can adjust the tilt arm by using the adjustment knob on the back of the arm. Slide the tilt arm left or right until the camera is balanced. Once balanced, tighten the clamp.
If you find that the camera is still swinging after adjusting the tilt arm, you may need to try adjusting the roll axis. Rotate the roll axis and adjust the arm until the camera stays in position without rotating back to the start position.
It is important to note that you may need to readjust the tripod plate after adjusting the tilt axis. This is mentioned in the user manual for the Ronin M, which provides detailed instructions on balancing the pan axis.
Effective Ways to Remove Stains from Your Muffin Pans
You may want to see also
Frequently asked questions
To balance the pan axis, adjust the position of the tilt arm until the camera stays still when you rotate the gimbal 90 degrees left and right. You can use the adjustment knob on the back of the tilt arm to slide the tilt arm left or right. Make sure the pan axis is dead in the middle and doesn't favor the right or left.
The setup process is rapid and easy, but there are some tricks to know to ensure you get it right. First, mount the grip to the gimbal and toggle the lever to the locked position. Attach the standard tripod to the grip. Unfold the tripod and place it on a level surface. Align the screws on the focus wheel with the M4 screw holes on the gimbal’s 8-pin ports. Tighten the 2 screws on the focus wheel with the hexagonal socket. Mount the camera dovetail plate to the camera and secure it with the screw. Attach the lens support to the camera dovetail plate to secure the lens. Tighten the gimbal pan axis; roll axis and tilt axis’ knobs. Slide the camera dovetail plate, mounted onto the camera mounting base, and tighten the lock.
After balancing the roll and pan axes, you can check the balance status of your gimbal using the DJI Ronin app on your smartphone or tablet. Connect your gimbal to the app via Bluetooth and tap the Balance Test button on the main screen. The app will show you the balance status of each axis and give you suggestions on how to improve it.
