Building a flue pan is no easy task, requiring a lot of practice and preparation. It is a time-consuming process that involves bending, welding, and soldering. A flue pan is used to increase the evaporation rate by creating more surface area. The smoke and other gases created by the fire travel through the flues of the pan, allowing for the capture of as much heat as possible from the wood. The size of the flue pan will determine the number of flues and their height. The purpose of the flues is to eliminate the build-up of sediments on the floor of the pan by allowing the flow of sap to be reversed.
| Characteristics | Values |
|---|---|
| Purpose | To increase the evaporation rate by creating more surface area |
| Flue size | 5" or 7", with deeper flues leading to a greater gallons-per-hour rate |
| Tools | Bending brake, vise grips, clamps, welding equipment |
| Time | 2-3 hours for bending, 2-3 hours for welding, 10-15 hours total |
| Cost | $250 CDN for a sheet of 20-gauge mill finish stainless steel |
| Advantages | Double the surface area, more efficient boiling, higher evaporation rate, less wood used, better syrup quality |
| Disadvantages | Time-consuming, difficult to clean |
Explore related products
What You'll Learn
Welding and soldering
On the other hand, soldering is a process in which two pieces of metal are joined without melting them. Instead, a dissimilar metal is used to fill the gaps. The solder dissolves and alloys with the metals being joined in a process called "wetting". Solder is not meant to provide high-strength connections, but rather to create a continuous connection.
When deciding whether to weld or solder a flue pan, there are several factors to consider. Firstly, welded pans are simpler to make and are more durable than soldered pans. If a soldered pan flexes too much, it will come apart unless the joints are locked together before soldering. Secondly, the design of the joints differs between welding and soldering. When welding a corner, the two edges are butted together and then fused. In contrast, soldering requires an overlapping joint, with solder used to seal between the overlapping pieces.
There are various techniques and tips for soldering flue tubes, which are components of flue pans. One technique involves coiling solder around a rod so that when relaxed, the coil can slip over the tube. The coil is then cut into closed-end rings, and a ring is placed over the end of each tube and covered with flux. Heat is then applied to the joint, causing the solder to flow into it. It is important to avoid putting the torch directly on the joint until the flux has melted into a clear liquid. Another technique for soldering copper tubes in a steel boiler involves extending the tubes past each plate and making axial notches around the bore. The boiler is then stood on each end so that the solder flows around the tubes and through the bore.
