Changing Oil Pan On A 2006 Chevy Hhr: Step-By-Step Guide

Changing the oil pan on a 2006 Chevy HHR can be a challenging task. It is important to identify the signs of an engine oil pan issue, such as oil spots under the vehicle, a sudden drop in oil level, an overheated engine, or black smoke from the engine. The average cost for an oil pan replacement is around $535, but the price can vary depending on the location, manufacturer, and vehicle model. The process of replacing the oil pan involves draining the old oil, removing the oil pan, cleaning the engine block surface, installing a new oil pan gasket, and tightening the bolts according to the manufacturer's specifications. It is recommended to consult a professional mechanic or refer to a detailed guide for a step-by-step procedure to ensure a safe and effective oil pan replacement.

Place a drain pan under the oil pan drain plug

To change the oil pan on a 2006 Chevy HHR, you'll first need to raise and support the vehicle. Place a drain pan under the oil pan drain plug. This will collect the oil as it drains out of the engine. Make sure the drain pan is positioned securely and won't topple over or leak. You can purchase a drain pan at an auto parts store or online.

Once the drain pan is in place, you can remove the oil pan drain plug. This will allow the oil to flow out of the engine and into the drain pan. Be careful not to strip the threads on the drain plug as you remove it, as this can cause leaks. After removing the drain plug, let the oil drain completely until it is no longer flowing from the pan.

At this point, you can proceed to remove the engine drive belt, the lower AC compressor bolt, and the oil pan bolts. Then, you can remove the oil pan itself. It's important to work carefully and methodically when performing these steps to avoid any damage to the engine or surrounding components.

Remove the oil pan drain plug

To remove the oil pan drain plug on a 2006 Chevy HHR, follow these steps:

First, raise and support the vehicle securely on jack stands. Place a drain pan or oil catch container under the oil pan drain plug. The drain plug is located on the backside of the oil pan. With your oil catch container ready, use a 15mm socket to loosen the oil pan drain plug. Once it is loose enough to turn with your fingers, position your catch container and remove the drain plug completely. Allow the oil to drain completely until it stops flowing from the pan.

Next, clean up any dirt or debris on the drain plug itself and around the oil pan. With everything clean, screw the drain plug back into the pan, being careful not to cross-thread it. Start by tightening it with your fingers, and then use a 15mm socket wrench to snug the drain plug securely in place without over-tightening.

Make sure to take your used oil to a location that recycles oil.

Drain the engine oil

To drain the engine oil from your 2006 Chevy HHR, first, raise the vehicle and support it securely on jackstands. Place a drain pan or oil catch container under the oil pan drain plug, which is located on the backside of the oil pan.

With your drain pan in place, use a 15mm socket to loosen the oil drain plug. Once it's loose enough to turn with your fingers, position the drain pan or container and remove the drain plug completely. Allow the oil to drain completely until it is no longer flowing from the pan.

With the oil drained, clean up any dirt or debris on the drain plug itself and around the oil pan. You can then re-screw the drain plug back into the pan, being careful not to cross-thread it. Start by tightening it with your fingers, then use a 15mm socket wrench to snug the drain plug without over-tightening.

Be sure to take your used oil to a location that recycles oil.

Remove the engine drive belt

To remove the engine drive belt on a 2006 Chevy HHR, you will need to relieve the tension on the belt and then remove it from the pulleys. Here is a step-by-step guide:

Step 1: Locate the Serpentine Belt Tensioner

The serpentine belt tensioner is responsible for keeping the belt taut. It is usually located near the crank pulley. Look for a square hole or a 15mm bolt in the middle of the tensioner.

Step 2: Relieve Belt Tension

To relieve the tension on the belt, you will need a special tool called a serpentine belt tool or a flat wrench with a welded 3/8" head. Insert this tool into the square hole or bolt in the tensioner and pull up to release the tension.

Step 3: Remove the Belt

With the tension released, you can now remove the belt. Start by looping the belt back over the A/C pulley and then gently releasing it from the alternator. Be careful not to let the tensioner snap back into place as you remove the belt.

Step 4: Work in a Comfortable Position

Accessing the belt can be challenging due to limited space. It is recommended to work from the passenger side of the vehicle and remove the passenger-side access panel underneath to gain better access from the bottom. Having a second person assist can also make the job easier.

Step 5: Install the New Belt

To install the new belt, start from the bottom and loop it over the crank pulley, A/C pulley, and tensioner. Push up on the tensioner and have your assistant loop the belt onto the alternator. Release the tensioner slowly to ensure the belt is seated correctly.

By following these steps, you can successfully remove and replace the engine drive belt on your 2006 Chevy HHR. Remember to work carefully and ensure that the belt is properly seated and tensioned before starting the engine.

Remove the oil pan bolts

To remove the oil pan bolts from a 2006 Chevy HHR, you will first need to raise and support the vehicle. Place a drain pan under the oil pan drain plug and remove the plug to drain the engine oil. Next, remove the engine drive belt and the lower AC compressor bolt.

Now, you can begin to remove the oil pan bolts. The number of bolts will vary depending on the model of your Chevy HHR. Once all the bolts have been removed, you can proceed to remove the oil pan itself.

It is important to note that the oil pan may be stuck in position due to the sealant. If this is the case, gently pry the oil pan to remove it.
