Pano Logic is a system that includes Pano Zero Clients, Pano Direct Service, and Pano Controller. Pano Zero Clients are virtual desktop deployments that use the Pano Direct Protocol (PDP) and do not require any special network configurations or equipment. The Pano Direct Protocol is highly efficient and does not require a CPU on the endpoint, which eliminates costly client storage and memory. Configuring Pano Logic involves setting up the system, connecting the JTAG programmer, and programming the SPI flash through JTAG. The process includes steps such as creating an 'mcs' file, performing a boundary scan test, and programming the SPI/BPI flash.
| Characteristics | Values |
|---|---|
| Programming language | iMPACT |
| File type | .msc |
| File location | .../xilinx/pano_z80.msc |
| File name | pano_hello_g1.msc |
| Bitstream file type | .bit |
| Bitstream file location | .../fw/hello_world |
| RISC-V image | RISC-V firmware |
| CPU | VexRiscV |
| SPI pins | Configures bitstream at power-up |
| SPI programming | Use "Short to Program" jumper and attach SPI programmer to the connector |
| Xilinx ISE MIG tool support | 8x and 16x regular DDR |
| Network type | Local area network (LAN) |
| Network speed | 100 Mbps (Megabits per second) |
| Protocol | Pano Direct Protocol (PDP) |
| PDP performance | Higher performance user experience with better support for rich multimedia and highly interactive applications over a LAN |
