Installing cap metal when overlapping with valley pan requires careful preparation and attention to detail. A valley is formed by two intersecting slopes on a metal roof, and proper installation is critical to prevent leaks, drafts, or structural damage. The process involves marking and cutting the valley pan to fit, ensuring proper overlap, and securing the pieces with screws and silicone sealant. It is important to follow the manufacturer's instructions and comply with local building code requirements. Additionally, the use of roofing underlayment and proper safety gear is crucial for a successful installation.
| Characteristics | Values |
|---|---|
| Purpose of valley trim | To prevent water, snow, and ice from rushing down the roof and to keep water from moving up the opposite slope and penetrating the roof |
| Installation of valley trim | Should be installed prior to the installation of the metal roofing panels |
| Cost of valley trim | Depends on the gauge, type of paint finish, and the size of the valley trim. On average, it costs $3 to $6 per lineal foot |
| Overhang and overlaps | Account for a minimum 1” overhang and 12” for overlaps |
| Installation steps | Mark the underside of the valley, cut it to fit, and then install it |
| Fasteners | Secure the overlap with fasteners, typically in the valleys of the corrugations |
| Sealant | Apply sealant or butyl tape between the sheets for extra protection against water infiltration |
| Chalk lines | Used to mark straight guidelines on flat surfaces |
| Ridge cap installation | Fasten the ridge cap with metal-to-metal fasteners at twelve-inch intervals |
| Overlapping ridge cap | Apply silicone sealant 2 inches from the inside of the overlap and overlap the ridge cap by 6 inches |
| Valley pan installation | Install the valley pan before putting in the offset cleat |
Explore related products
What You'll Learn
Prepare the roof with underlayment and eave trim
Before installing cap metal when overlapping with valley pan, it is important to prepare the roof with underlayment and eave trim. Here is a step-by-step guide to help you through the process:
Prepare the Roof with Underlayment:
Firstly, ensure that proper roofing underlayment is installed. Underlayment is a crucial component of any metal roofing system, providing an extra layer of protection against the elements. It should be installed prior to the eave flashing and valley trim to create a weather-tight barrier.
Install the Eave Trim:
Eave trim, also known as eave flashing, is the metal flashing that covers the low side of the building. It works in conjunction with the underlayment to prevent water from blowing underneath the roof. Here are the steps to install it:
- Place the eave trim over the underlayment, ensuring it sits securely.
- Use screws to secure the eave trim in place. The recommended spacing is one screw located at 8 inches from each end of the eave flashing, and then screws spaced twelve inches apart in between.
- Cut an eight-inch strip of suitable underlayment material, such as Sharkskin Ultra SA, and install it over the eave flashing.
- You will now have underlayment both underneath and over the eave trim, providing extra protection.
Prepare for Valley Trim Installation:
Now that the underlayment and eave trim are in place, you are ready to begin installing the valley trim. Valley trim is crucial to preventing water from travelling up the opposite slope and penetrating your roof. Here are the initial steps to prepare for valley trim installation:
- Mark and cut the valley trim to fit where the eaves meet at the inside corner, ensuring it aligns with the ridge line and eave trim edge.
- Place tape sealant or silicone sealant between metals to prevent water from getting underneath.
By following these steps, you will have successfully prepared your roof with underlayment and eave trim, ready for the installation of cap metal when overlapping with valley pan.
