Installing new floor pans is a common task when restoring an old car, especially if you're dealing with a rare model. Fabricating your own floor pans can be a great way to restore an old, rusty car, and while it may seem daunting, the process is not too complicated. This guide will take you through the steps to install Model A floor pans, covering everything from the tools and materials you'll need to the fabrication and installation process.
| Characteristics | Values |
|---|---|
| First Step | Cutting out the original floor sheet metal and removing rusted areas |
| Tools | Plasma cutter, cutoff wheel, body hammer, cutting wheel, wide sheet metal pliers, drill and bits, chisels, die grinder with sanding discs, straight edge, measuring tape, poster board, scissors, pencil/marker, yardstick, wooden straight edge, etc. |
| Template Creation | Use poster board, manila folders, or cardboard to trace the pattern of the floorpan, kick panels, and any necessary holes, leaving room for welding overlap |
| Sheet Metal | Use 14-18 gauge sheet metal, depending on the original thickness and personal preference. Transfer the template pattern to the sheet metal and cut using a plasma torch |
| Test Fitting | Test fit the new panels to ensure proper alignment and make any necessary adjustments |
| Painting | Paint the underlying structure to protect it from rust and apply a weld-through primer to prevent corrosion |
| Welding | Use the stitch method or intermittent welding, welding an inch, skipping an inch, and repeating until the panel is secure |
| Challenges | Finding good quality floor pans for rare vehicles can be difficult and expensive |
