Ohming out a refrigerator compressor is a critical diagnostic step to determine if the compressor motor is functioning properly or if it has failed. This process involves using a multimeter to measure the resistance (ohms) across the compressor’s terminals, which helps identify issues such as open or short circuits, burnt windings, or faulty start relays. By disconnecting power to the refrigerator, accessing the compressor’s wiring, and testing the resistance between specific terminals, you can pinpoint whether the compressor is the source of cooling problems. This method is essential for troubleshooting and deciding whether the compressor needs repair or replacement.
| Characteristics | Values |
|---|---|
| Purpose | To test the electrical resistance of the compressor motor windings. |
| Tools Required | Multimeter (set to ohms/resistance mode), insulated gloves, safety gear. |
| Safety Precautions | Disconnect power, discharge capacitor, wear insulated gloves. |
| Steps | 1. Disconnect power. 2. Access compressor terminals. 3. Set multimeter to ohms. 4. Test resistance between terminals. |
| Terminals to Test | Common (C), Start (S), Run (R). |
| Expected Resistance Range | Varies by model; typically 1-10 ohms for Run winding, 5-20 ohms for Start winding. |
| Open Circuit Reading | Infinite resistance (OL or 1 on multimeter). |
| Short Circuit Reading | Very low resistance (close to 0 ohms). |
| Capacitor Discharge | Mandatory before testing to prevent electrical shock. |
| Normal Readings | Consistent with manufacturer specifications (check service manual). |
| Abnormal Readings | Open or short circuit indicates a faulty compressor. |
| Post-Test Action | Reconnect power only if readings are normal. |
| Professional Assistance | Recommended if unsure or if compressor is faulty. |
Explore related products
What You'll Learn
- Safety Precautions: Ensure power is disconnected before testing to prevent electrical shock or injury
- Tools Required: Multimeter, insulated gloves, screwdriver, and safety goggles for accurate and safe testing
- Locating Terminals: Identify compressor terminals (start, run, common) for proper ohm reading placement
- Testing Resistance: Measure ohms between terminals to check for continuity and detect faults
- Interpreting Results: Compare readings to specifications to diagnose compressor health or issues
Safety Precautions: Ensure power is disconnected before testing to prevent electrical shock or injury
Before attempting to ohm out a refrigerator compressor, the single most critical step is to ensure the power is completely disconnected. This isn’t a suggestion—it’s a non-negotiable safety measure. Refrigerator compressors operate on high voltage, typically 110-120V in residential settings, and even a brief contact with live wires can result in severe electrical shock, burns, or fatal injury. Always verify power disconnection by using a non-contact voltage tester on the compressor terminals and the power source. Never assume the appliance is off simply because it’s unplugged or the breaker is flipped; double-checking takes seconds and could save a life.
The process of disconnecting power involves more than just unplugging the refrigerator. For hardwired units, locate the circuit breaker in your electrical panel and switch it off. Tag the breaker to prevent accidental re-energization during testing. If the compressor is in a commercial or older unit, consult the wiring diagram to identify all potential power sources, including backup systems or shared circuits. Failure to isolate all power feeds can leave hazardous voltage present, even if the main power appears off. Treat every wire as live until confirmed otherwise.
Once power is disconnected, proceed with caution. Allow the compressor to discharge any residual capacitance, which can hold a dangerous charge for several minutes. Use an insulated screwdriver with a rubber grip to short the compressor terminals to ground, ensuring any stored energy is safely released. When testing for continuity or resistance, use a digital multimeter with insulated leads and wear rubber gloves to minimize contact risk. Avoid touching metal surfaces or standing on wet floors during testing, as these increase the risk of grounding yourself and completing a dangerous circuit.
Even with power disconnected, maintain situational awareness. Work in a well-lit area with dry hands and stable footing. Keep tools and testing equipment organized to prevent accidental contact with exposed wires. If you’re unsure about any step, consult a professional or reference detailed manuals specific to your refrigerator model. Skipping safety precautions to save time is a gamble with irreversible consequences. Prioritizing safety ensures the task is completed without injury, making it the foundation of any successful compressor test.
