XYZmaker is a 3D printing software that allows users to convert 2D images into 3D models. The software provides a range of tools and plugins to enhance the 3D printing experience, including the ability to combine multiple objects in the workplane and duplicate objects. Users can also adjust the unit of measurement and grid size, as well as customise the display settings to their preference. While the software offers a basic editing toolbar, it also has more advanced features, such as the ability to use built-in plugins like the Geometry Generator Plugin and Photo Emboss.
| Characteristics | Values |
|---|---|
| File Types Supported | STL, AMF, PLY, OBJ, 3MF and 3w |
| Saving Files | "Save" updates the last saved version; "Save As" saves work with a different name |
| Combining Objects | Use the "Add Item" function, or the built-in "Geometry Generator Plugin", "Object Array", "Triangular Subdivision", "Photo Emboss" and "Reduce Mesh" |
| Removing Objects | Use the function in the Toolbar |
| Clone Function | Duplicates the selected object and pastes it in the original position |
| Group Function | Combines two or more objects into a single object that can be moved as one |
| Align Function | Moves and aligns objects in one command |
| Unit of Measurement | Millimetres, centimetres, or inches |
| Image Conversion | Convert 2D images (JPEG, PNG) into 3D |
| Shortcut Keys | Provide quick navigation and execution of commands |
| Preferences | Customise the colour of the main window, language, autosave, background, object colour, and where to save the project |
Explore related products
What You'll Learn
Using the Clone function to duplicate objects
XYZmaker offers a Clone function that allows users to duplicate selected objects. This function is accessible via the Edit menu or the Toolbar. To use the Clone function:
- Import or select an object on the workplane.
- Click the Clone icon on the Toolbar.
- The object will be duplicated and pasted in its original position.
- To view the duplicated object, use the Move function to adjust its position.
It is important to note that the Clone function only duplicates the object in its original position. To create duplicates in different positions or arrangements, users can explore other functions in XYZmaker, such as the Object Array plugin, which offers Array Copy 1D, Array Copy 2D, and Array Copy Circle options for duplicating objects.
Additionally, the Mirror function can create a reflection of an object in a reversed position. This function is useful for creating duplicates with different orientations without manually repositioning them.
Stove Drip Pans: Cost and Maintenance
You may want to see also
Explore related products
Combining objects with the Group function
The Group function in XYZmaker allows you to combine two or more objects into a single object that can be moved as one. This is especially useful when you want to move and align several objects together in one command.
To group objects, first, select two or more objects using the Ctrl key. Then, click the Group button or use the shortcut Ctrl + G.
Once the objects are grouped, you can use the Align command to move and align the objects in one action. Simply select the objects you want to align, click the Align button, and move your mouse to the desired position. The lines provided will guide you, with the red line indicating alignment on the X-axis, the green line on the Y-axis, and the blue line on the Z-axis.
In addition to the Group function, XYZmaker also offers a Hole function that allows you to subtract one object from another. This function can be used on single or grouped objects. To use the Hole function, select the base object, click H, then click the object you want to remove and click H again. Alternatively, you can click the Hole button in the Toolbar.
Explore Panning Techniques: A Guide to Hearing Stereo Depth
You may want to see also
Explore related products
Using the Add Item function to insert objects
XYZmaker is a software that allows users to create 3D models and images. The software has a built-in model gallery where users can quickly create models and access recently used shapes. The modelling tools list is separated into recently used shapes, geometric figures, letter galleries, number galleries, symbol galleries, and special shape galleries.
The "Add Item" function in XYZmaker allows users to insert and combine multiple objects in the workplane. This function enables users to add as many objects as needed to their current project. It is important to note that the "Add Item" function does not combine objects in the model bar to create new objects. Instead, it offers the option to use built-in plugins to enhance the project. These plugins include the Geometry Generator Plugin, Object Array, Triangular Subdivision, Photo Emboss, and Reduce Mesh.
To use the "Add Item" function, follow these steps:
- Open the XYZmaker software and set up your project.
- Go to the Edit menu or the Toolbar, where you will find the "Add Item" function.
- Select the "Add Item" function to activate it.
- Choose the objects you want to insert into your project.
- Use the Ctrl key to select two or more objects, and then click the "Group" button or use the Ctrl + G shortcut to combine them into a single object.
- Move and align the objects as needed using the Align command. The software will provide coloured lines to guide you through the alignment process.
- Continue adding and combining objects as desired to create your scene or model.
The "Add Item" function in XYZmaker provides users with the flexibility to add and combine multiple objects in their projects. By using the Ctrl key and the Group function, users can easily create complex scenes or models by grouping and arranging objects precisely.
Panning for Gold: Cleaning Your Precious Find
You may want to see also
Converting 2D images into 3D
XYZmaker is a software that can help you convert 2D images into 3D images. The process is simple: click on Plugin, select Photo Emboss, and then Load Picture to select any PNG or JPG image. After this, you will need to select the type of photo emboss you want to use, either Stereo Board or Stereo Board Cylinder.
XYZmaker also has a modelling toolbar with a built-in model gallery, which allows users to quickly create models. The modelling tools list is separated into recently used shapes, geometric figures, and a 3D text generator.
There are other tools available that can convert 2D images into 3D models, such as Meshy, an AI tool that can quickly convert 2D images into 3D models. Users simply upload a picture and wait for a refined 3D model. Another tool is ImageToStl, which can convert 2D images into 3D STL Mesh Model Files. This tool is free and can be used to convert 2D images into 3D models suitable for printing with a 3D printer.
Dzine is another 2D to 3D image converter that offers a variety of style options and filters to add a unique touch to your artwork. This tool is user-friendly and requires no special skills or technical knowledge.
Retightening Oil Pan Plug: A Step-by-Step Guide
You may want to see also
Changing units of measurement
XYZmaker allows you to change the units of measurement of your object. The default size of the grid is set to millimetres, but you can change it to centimetres or inches. The unit size of your object will depend on the selected grid size.
To change the unit of measurement, go to the Grid function. Here, you can also see a preview of your model inside the printer in the Printer Plugin Window. This preview can help you avoid designing objects that are too large for your printer or that exceed the printable boundary.
The Grid function also allows you to move and align objects in one command. You can select the objects you want to align and click the Align button. The mouse pointer will then indicate the position of alignment. The red line indicates alignment on the X-axis, the green line on the Y-axis, and the blue line on the Z-axis.
XYZmaker also has a Jog mode that allows you to freely move the extruder module along the X, Y, and Z axes. This is useful for printer maintenance and repair, as it allows you to manually adjust the movement of the axes. To use Jog mode, first click on "Home Axes". This will return the printing device to its initial axis position at the lower left corner of the printing area. You can then adjust the positions of the printing module (X-axis), printing platform (Y-axis), and printing axes (Z-axis).
Tightening the Oil Pan Drain Plug: How Much is Too Much?
You may want to see also
Frequently asked questions
Click on the home icon to reset your viewing angle. You can also use the view finder reference cube on the left-hand side of the screen to help you.
XYZmaker has a function that allows you to remove an object from the workplane.
Use the Group Function to combine two or more objects into a single object. First, select the objects you want to combine using the Ctrl key, then click the Group button or Ctrl + G.
Use the Clone function to duplicate an object and paste it in its original position. Move the object to see the clone.
Click on Plugin and select Photo Emboss. Then, click Load Picture and select your image. Finally, choose the type of photo emboss you want to use, either Stereo Board or Stereo Board Cylinder.
