Slow panning is a pivotal camera movement technique that allows audiences to absorb the intricacies of a scene, establishing the location and tracking the movement of characters or objects within it. This article will explore the setup of a slow pan on the Mimic, a Freefly camera movement system. The Mimic's MIMIC Mode allows for intuitive control of the pan, tilt, and roll movements by physically moving the Mōvi Controller. This article will provide a step-by-step guide to setting up a slow pan, including calibration, scaling, and re-orientation procedures, to help filmmakers craft suspenseful and revealing shots.
| Characteristics | Values |
|---|---|
| How to set up slow pan on the Mimic | MIMIC Mode allows for intuitive control of the Mōvi pan, tilt, and (optionally) roll by physically moving the Mōvi Controller |
| Mount the Mōvi Controller to a fluid head tripod for smooth pan bar-like control, or move it in your hands for dynamic yet stable operation | |
| MIMIC Mode can translate Mōvi Controller movement to the Mōvi directly (1:1) or it can scale the movement on each axis | |
| Use the Mimic Axis Scale values for Roll, Tilt, and Pan to adjust this behavior | |
| The USER 1 and USER 2 Knobs can be optionally mapped to Pan and Tilt Trim, to cancel any small movements in these axes | |
| How to set up slow pan in film | A pan allows the audience to see more of the scene and establish the location |
| A slow pan can also be used to track the movement of characters or objects within that location | |
| A slow pan can delay action and build anticipation | |
| A slow pan can be used to build suspense |
Explore related products
What You'll Learn
Use MIMIC Mode for intuitive control of pan, tilt and roll
MIMIC Mode allows for intuitive control of the Mōvi pan, tilt, and roll by physically moving the Mōvi Controller. This mode is available in Mōvi Controller firmware v2.0 and later and is compatible with any Mōvi using firmware v4.2 or later. To check the firmware version, simply highlight the Home icon on the Home screen.
MIMIC Mode uses sensors in the Mōvi Controller to measure its movement. These sensors are calibrated each time the controller is turned on, which takes approximately five seconds. During this time, the controller should be kept level and still. If the controller was moving during start-up, or if one or more axes drift while using MIMIC Mode, the sensors can be re-zeroed from the Tx Config menu.
When using MIMIC Mode, you can either mount the Mōvi Controller to a fluid head tripod for smooth pan bar-like control or move it in your hands for dynamic yet stable operation. The mode can translate Mōvi Controller movement to the Mōvi directly (1:1) or scale the movement on each axis using the Mimic Axis Scale values for Roll, Tilt, and Pan. For example, by default, the Mimic Roll Scale is set to 0.0 (disabled). To enable the roll axis with a direct ratio of 1:1, set the Mimic Roll Scale value to 1.0. Similarly, while the Pan and Tilt Scale are set to 1.0 by default, using a higher Scale may be advantageous if the Mōvi Controller is mounted on a tripod. For instance, by setting the Tilt Scale to 3.0, you only need to tilt the Controller 30º up or down to move the Mōvi tilt axis by 90º.
Additionally, the USER 1 and USER 2 Knobs can be optionally mapped to Pan and Tilt Trim to cancel any small movements in these axes. The joystick can also be used to reframe while in MIMIC Mode, such as aligning the camera for a shot. If you want to disable the joystick input, set the Pan and Tilt Speed knobs to their minimum position.
Removing Drip Pans and Pan Rings: A Step-by-Step Guide
You may want to see also
Explore related products
Mount the controller to a tripod for smooth pans
To achieve smooth pans, it is recommended to mount the controller to a tripod. This can be done by first attaching a pan-and-tilt head to the tripod. If the head on your tripod can be removed, simply rotate it off and screw on the pan-and-tilt head. If your tripod does not have a removable head, you can try loosening the grub screws on the underside to spin it off. Make sure the pan-and-tilt head fits the correct mount on your tripod, such as 1/4-inch or 3/8-inch.
Once the pan-and-tilt head is attached, mount your camera onto it using a quick-release plate. If you are using a long telephoto lens, it is advisable to mount it to the tripod collar instead to distribute the weight evenly.
To achieve smoother pans, you can adjust the fluidity settings on the pan-and-tilt head, especially if you are using a large lens. Additionally, you can extend the length of the panning handle by using a metal or plastic pipe, or a long cardboard tube, to gain more control over the movement.
When using a tripod, it is important to ensure that it is stable and balanced. Consider using a heavier tripod and head than what is required for your camera setup. You can also add weight to the camera by attaching small counterweights to mounting holes on the top of the camera or carrying handle.
By following these steps and adjustments, you can effectively mount the controller to a tripod and achieve smooth pans for your shots.
Growing Beards: Small Pan, Big Results
You may want to see also
Explore related products
Adjust Mimic Axis Scale values for roll, tilt and pan
When using MIMIC Mode on the Mōvi Controller, you can adjust the Mimic Axis Scale values for roll, tilt, and pan to fine-tune your movement. MIMIC Mode allows you to physically move the Mōvi Controller to intuitively control the Mōvi's pan, tilt, and roll.
By default, the roll axis is disabled (Mimic Roll Scale: 0.0). If you want to enable the roll axis with a direct 1:1 ratio, set the Mimic Roll Scale value to 1.0. The pan and tilt scales are set to 1.0 by default. However, if you have your Mōvi Controller mounted on a fluid head tripod, you may want to increase these values. For example, setting the Tilt Scale to 3.0 means that tilting the controller 30 degrees up or down will move the Mōvi tilt axis by 90 degrees. This allows for more precise and slow pan movements.
The USER 1 and USER 2 Knobs can be mapped to Pan and Tilt Trim to cancel any small movements in these axes and ensure smooth and stable operation. Additionally, the joystick can be used to reframe while in MIMIC Mode. If you want to disable this input, set the Pan and Tilt Speed knobs to their minimum position.
It's important to note that in MIMIC Mode, the sensors in the Mōvi Controller are calibrated each time it is turned on. Keep the controller level and still during start-up to ensure accurate calibration. If the controller was moving during start-up, or if axis drift occurs during use, you can re-zero the sensors from the Tx Config menu.
The Mimic Axis Scale values allow you to customize the responsiveness of the Mōvi to your controller movements, providing a dynamic and controlled shooting experience.
Cleaning Amber-Colored Stains from Your Stainless Steel Pan
You may want to see also
Explore related products
Use the Pan Freeze button to reorient the Mimic Beta with the Movi
The Mimic Beta can be reoriented with the Movi using the Pan Freeze button. This button is located next to the right handlebar grip. To reorient the Mimic Beta, press and hold the Pan Freeze button and pan the Mimic Beta. While the button is pressed, the Movi pan stays locked in pan orientation, regardless of where the Mimic Beta pans. Once the button is released, the Mimic Beta will continue to command the Movi pan movements but at a new orientation.
It is important to note that the Pan Freeze feature will not work if either the Movi or Mimic Beta are in a heading assist mode. Additionally, do not press the Pan Freeze button while the Mimic Beta is turning on, as this will require a power cycle.
If you are experiencing pan drift when using the Pan Freeze button to realign the Mimic operator and Movi heading, this can be solved by using Compass Heading Assist. Both the Movi and Mimic Beta require compass calibrations for the Compass Heading Assist to function properly. These calibrations can be performed using the Freefly Movi App. Once the calibrations are complete, change Heading Assist to Compass for the Movi in the Expert menu and Mimic in the General menu. However, note that when Compass Heading Assist is enabled, the Pan Freeze button will not function.
By following these steps, you can use the Pan Freeze button to reorient the Mimic Beta with the Movi and adjust their orientations to achieve the desired camera movements for your filming or photography needs.
Stop Food Sticking: Pan-Oven Tricks and Tips
You may want to see also
Explore related products
Calibrate the compass to enable Compass Heading Assist
Calibrating the compass of your Mimic Beta is necessary when changing the Heading Assist to Compass in the Freefly App. This process will disable the Pan Freeze button on the Mimic Beta. To perform a compass calibration, open the Freefly Mōvi App.
For the M-Series Mōvi, select SYSTEM, then Compass Calibration, and open the terminal. Follow the text instructions. For the Mimic, select the Start Compass Cal parameter under the General menu, and click the right arrow to initiate the process. Once in the terminal, follow the text instructions.
After calibrating the compass for both the M-Series Mōvi and the Mimic Beta, change the Heading Assist to Compass for the Mōvi in the Expert menu. For the Mimic, change it in the General menu.
It is important to note that when Compass Heading Assist is enabled, the Pan Freeze button will not work. The value of your declination, which is determined by your current geographical location, needs to be set manually by you.
The Secret to Taiwanese Hot Pot Sauce: A Step-by-Step Guide
You may want to see also
Frequently asked questions
A slow pan is a deliberate and slow panning movement back and forth across a scene. It allows the audience to take in the details of a landscape or the faces in a crowd. It is used to build suspense and establish the location.
To set up a slow pan on the Mimic, you need to use the Pan Freeze button to reorient the Mimic Beta with the Movi. While the button is pressed, the Movi pan stays locked in pan orientation regardless of where the Mimic Beta pans.
MIMIC Mode allows for intuitive control of the Movi pan, tilt, and (optionally) roll by physically moving the Movi Controller. It is available in Movi Controller firmware v2.0 and later and is compatible with any Movi using firmware v4.2 or later.
To set up MIMIC Mode, mount the Movi Controller to a fluid head tripod for smooth pan bar-like control, or move it in your hands for dynamic yet stable operation. MIMIC Mode uses sensors in the Movi Controller to measure its movement, and these sensors are calibrated each time the Movi Controller is turned on.
