The Pre-Pitch and Quick-Pitch kits are both used to create a slope for water to drain away in a shower. The Pre-Pitch kit is used first to create a slope for the membrane to sit on, and then the Quick-Pitch kit is used on top of the membrane to create a slope for the tile. This ensures that any water that gets through the tile and grout will hit the membrane and drain away, rather than becoming trapped and causing mould. Some professionals choose to use only the Quick-Pitch kit, installing a vinyl liner directly onto a flat surface. However, others argue that a pre-slope is imperative to ensure that water does not stagnate.
| Characteristics | Values |
|---|---|
| Purpose of Pre-Pitch | To provide a slope underneath the shower pan liner so that water that goes through the mortar bed is directed toward the drain, preventing mould and mildew |
| Purpose of Quick-Pitch | To be placed on top of the shower pan liner, creating a mortar bed in which tiles are set |
| Pre-Pitch slope | 1/4" per foot |
| Quick-Pitch slope | 1/4" per foot |
| Installation order | Pre-Pitch is used first, followed by the membrane, then Quick-Pitch |
| Use case | Recommended for wooden sub-floors to ensure proper drying of the mortar bed |
| Pre-Pitch kit contents | Does not include a drain centre ring; includes sticks to establish a slope for the dry pack |
| Quick-Pitch kit contents | Includes a drain centre ring |
| Pre-Pitch and Quick-Pitch combination | The two slopes do not create a noticeable double slope when combined |
| Pre-fabricated shower pan liner options | OneLiner (made from polyethylene), PVC pan liner, Red Gard |
| Alternative methods | Pouring your own pan using the Schluter system or a single/double pour concrete pan with a membrane in between |
Explore related products
What You'll Learn
The Pre-Pitch kit does not include a drain centre ring
The Pre-Pitch kit is the first step in building a shower base. It is placed on the subfloor to create a slope that directs water towards the drain, preventing mould and mildew. The kit includes float sticks, screws, double-sided tape, and an installation pamphlet. It does not include a drain centre ring. Instead, it establishes the slope of the dry pack down to the drain, which is then covered with a vinyl liner. The Quick-Pitch kit is used on top of the Pre-Pitch kit and includes the drain centre ring.
The Pre-Pitch kit's float sticks are used to create a slope for the shower floor. This slope ensures that water flows towards the drain, preventing it from sitting on a flat surface and causing mould and mildew. The sticks are placed on the subfloor, whether it is wooden or concrete, and are secured with the included screws and double-sided tape. The number of sticks required depends on the size and shape of the shower. While the standard kit comes with six sticks, some users have noted that eight sticks may be needed for larger showers.
The Pre-Pitch kit establishes the slope of the dry pack down to the drain. This is done by adjusting the threaded body of the drain assembly to raise the top drain flange. This ensures that the overall height of the mud surrounding the drain is increased, maintaining the necessary distance between the vinyl clamping ring and the flange. The slope created by the Pre-Pitch kit is 1/4" per foot, which is the recommended slope for shower floors.
The Quick-Pitch kit is then used on top of the vinyl liner. This kit includes the drain centre ring, which rests on the top edge of the drain. The Quick-Pitch sticks sit on this centre ring, maintaining the 1/4" per foot slope. The Quick-Pitch kit is used to set the tile for the shower floor. It is important to note that the Quick-Pitch kit should be used in conjunction with the Pre-Pitch kit to ensure proper drainage and prevent mould and mildew.
While some professionals choose to use only the Quick-Pitch kit, installing a vinyl liner directly on a flat surface, the Pre-Pitch kit provides an added layer of protection against water damage and mould. It is recommended to use both kits for a proper slope and drainage, especially when using a 40mil Vinyl Liner for waterproofing.
Accessing Your HVAC's Drip Pan: A Step-by-Step Guide
You may want to see also
Explore related products
The Quick Pitch kit includes a drain centre ring
The Quick Pitch kit is a shower floor drainage kit that creates a perfect shower floor-base slope to drain water from the shower floor. The Quick Pitch kit includes a drain centre ring and tapered float sticks to ensure the correct drainage slope in standard or custom shower areas. The Quick Pitch kit is placed on top of the shower pan liner, which is the second part of the system after the Pre-Pitch. The Pre-Pitch is placed on the sub-floor to provide a slope underneath the shower pan liner, directing water towards the drain and preventing mould and mildew. The Quick Pitch kit is then placed on top of the shower pan liner, creating a mortar bed for setting tiles.
The Quick Pitch Float Stick System uses a centre ring and tapered float sticks to assure the correct drainage slope. The centre ring sits on top of the drain flange bolts, and the float sticks attach to the centre ring in any of the 24 slots. The standard kit includes six float sticks with a 1" to 1-3/4" taper x 36" long, and one centre ring. The Quick Pitch kit can be used for standard 36" x 60" shower areas with a centred drain or custom shower areas where the drain is within 36" of each wall.
The Quick Pitch kit is designed to be easy to use and ensures proper drainage slope without the need for measurements or levels. It is important to note that the Quick Pitch kit is placed on top of the Pre-Pitch system, creating a double slope that is not noticeable when standing inside the shower. The combination of the Pre-Pitch and Quick Pitch systems helps to ensure proper water drainage and prevent mould and mildew.
The Quick Pitch Universal Centre Ring is designed to accommodate 2" and 3" shower drains, square drain risers, and most other specialty shower drains. It includes 2" and 3" inserts to match the threaded riser portion of the drain and a 6" inside diameter top ring to accommodate square or oversized drains. The universal centre ring is made of high-impact plastic, ensuring durability and lightweight construction. It is important to note that the universal centre ring is designed for larger drain sizes and may not work with shallow-threaded drains.
Easy Oil Change: X3's Innovative Drain Pan
You may want to see also
Explore related products
The Pre-Pitch system provides a slope for the membrane
The Pre-Pitch system is an innovative tool that creates a subtle slope beneath the pan liner, ensuring efficient water flow towards the weep holes in shower floor drains. This simple yet effective mechanism prevents water from becoming trapped between the mud bed and the liner, which is a common cause of mould and mildew issues. By facilitating water drainage, the Pre-Pitch system helps maintain a clean and dry shower environment.
The Pre-Pitch system is designed to be installed on a variety of sub-floor surfaces, including wood and concrete. It is easy to use and can be cut to fit the specific dimensions of your shower. The system comprises lightweight sticks that are positioned beneath the pan liner, with the thin end of each stick remaining approximately 1/2 inch away from the drain's bottom flange. This strategic placement creates a slight slope, guiding water towards the drain.
The Pre-Pitch system is particularly beneficial when used in conjunction with the Quick Pitch system. While both systems contribute to effective water drainage, they do so in distinct ways. The Pre-Pitch system acts as the foundational slope, while the Quick Pitch system is placed on top of the shower pan liner, providing additional reinforcement to the mud bed.
When combined, the Pre-Pitch and Quick Pitch systems ensure optimal water flow and drainage. The Quick Pitch system includes a centre ring that sits on top of the drain, raising the overall system and preventing the slope from becoming too steep. This design feature ensures a comfortable showering experience, even with the dual-slope setup.
In summary, the Pre-Pitch system is an essential component for any shower installation. By creating a subtle slope beneath the pan liner, it facilitates proper water drainage, inhibits mould and mildew growth, and promotes a long-lasting, hygienic shower environment. The Pre-Pitch system is easy to install, adaptable to various shower configurations, and works seamlessly with the Quick Pitch system to provide efficient water management solutions.
Shortening a VW Pan for Dune Buggies: A Step-by-Step Guide
You may want to see also
Explore related products
The Quick Pitch kit gets the slope right for the tile
The Quick Pitch kit is an essential component of the shower installation process, ensuring a proper slope for tile placement. This kit, combined with the Pre-Pitch system, guarantees that water will efficiently drain away, preventing mould and mildew issues.
The Quick Pitch kit is placed on top of the shower pan liner, serving as the mortar bed for tile setting. It achieves a precise 1/4" per foot slope, which is crucial for effective drainage. This slope is maintained by the kit's components, including the centre ring and tapered float sticks, which work together to assure the correct drainage slope.
The Pre-Pitch system is the first step, placed on the subfloor to create a slope beneath the shower pan liner. This initial slope guides water towards the drain, preventing it from sitting on a flat surface and causing mould issues. The combination of Pre-Pitch and Quick-Pitch creates a "`double slope", but it's designed so that it's unnoticeable when standing in the shower.
The Quick Pitch kit's adjustability allows for customisation to fit various shower sizes and shapes. It can be extended for showers larger than the standard 3x5 dimensions. Additionally, the kit eliminates the need for complex measurements or levelling tools, making it a time-saving solution for achieving a perfectly sloped shower floor.
Overall, the Quick Pitch kit plays a vital role in getting the slope right for tile installation in shower areas. Its ease of use and accuracy in achieving the desired slope make it a popular choice among customers, ensuring proper drainage and preventing water-related issues.
Is Your Water Boiling? Here's How to Tell
You may want to see also
Explore related products
The Quick Pitch system is placed on top of the shower pan liner
The Quick Pitch system is then placed on top of the shower pan liner. This creates a mortar bed with a slope of 1/4" per foot, which ensures that water is directed towards the drain. This prevents water from sitting on a flat surface, reducing the chance for mould and mildew to build up. The Quick Pitch system is adjustable, allowing you to achieve your desired pitch.
When using the Quick Pitch system, it is important to first determine the dimensions of your shower and the placement of your drain. This will help you establish how many Pre-Pitch and Quick-Pitch kits or singles you will need. You will also need to decide on the type and size of shower pan liner that you will use. Options include a pre-fabricated OneLiner shower pan liner, a PVC pan liner, or Red Gard.
The Quick Pitch system is designed to be used with any liner system and can be adjusted to achieve your desired slope. It is important to note that the system does not add to the pan liner pre-slope as the Center Ring sits on top of the drain flange bolts. By following these steps and using the Quick Pitch system, you can ensure a properly sloped shower floor without the need for measurements or a level.
Baking Lemon Bars: Jelly Roll Pan Edition
You may want to see also
Frequently asked questions
Yes, you can. The Pre-Pitch is used first to create a slope for the membrane to sit on. Then, the Quick Pitch is placed on top of the membrane. This ensures that any water that gets through the tile and grout will hit the membrane and drain, preventing mould.
The Pre-Pitch provides a proper slope underneath your shower pan liner, so that water that goes through your mortar bed is directed towards your drain. The Quick Pitch is then placed on top of the shower pan liner, creating a mortar bed for your tile.
It depends on whether you plan on doing a pre-slope under a vinyl liner. Some professionals simply lay a vinyl liner on a flat surface and then construct a dry pack with a 1/4" per foot slope on top. In this case, you only need the Quick Pitch kit.
The slope in a wet-area pan is to motivate all water towards the drain. Without a pre-incline, water will sit on your waterproof liner and stagnate, leading to mould.
You can create your own shower pan by pouring concrete and using the Schluter system, or another waterproofing membrane. This is a relatively inexpensive option but requires more skill to achieve the correct slope.
