Weiand Stealth Intake: Valley Pan Gasket Required?

The Weiand Stealth intake manifold is an aftermarket aluminium manifold that does not require the use of a valley pan gasket. In fact, the manufacturer specifically instructs users not to use a valley pan intake gasket with this product. The purpose of a valley pan gasket is to prevent oil from baking underneath the manifold, but this is not necessary with the Weiand Stealth as it is made from aluminium, which conducts heat efficiently.

The Weiand Stealth intake manifold may not need a valley pan gasket

If you are using an aftermarket aluminium intake manifold and blocking off the exhaust crossover passage, a valley pan gasket is not necessary as there isn't any additional source of heat. However, if your intake manifold and cylinder heads have an exhaust crossover passage and you are using it, it is recommended to use a valley pan-type gasket.

It is important to note that the purpose of the valley pan is to prevent oil from baking underneath the manifold and to keep the intake air charge cool, which can affect horsepower. Some people choose to use a valley pan gasket to keep the underside of the intake manifold clean, while others do not experience any issues without it. Ultimately, the decision to use a valley pan gasket with the Weiand Stealth intake manifold depends on the specific application and personal preference.

The valley pan gasket is used to keep oil off the intake manifold

The valley pan gasket is an important component in an engine, serving as both a gasket and an oil splash guard. Its primary function is to prevent oil from splashing onto the bottom of the intake manifold, keeping it clean and free from caked-on oil. This is especially important for cast iron intakes, where hot oil can increase the temperature of the manifold.

The valley pan gasket is typically made of metal, such as aluminium or steel, and fits between the cylinder heads and the intake manifold. It is designed to seal the intake ports while allowing oil to drain through drain holes in the pan. This design helps keep the intake manifold clean and prevents carbon buildup under the manifold, which can contaminate the oil.

The use of a valley pan gasket is recommended when using an intake manifold with an exhaust crossover passage. In this case, the gasket acts as an oil barrier for the exhaust crossover passage, preventing oil from baking underneath the manifold. However, some intake manifold manufacturers, such as Weiand Stealth, instruct users not to use a valley pan gasket with their products.

When installing a valley pan gasket, it is crucial to ensure proper sealing. This can be achieved by using a light layer of high-temperature silicone sealant around the intake ports and a heavier layer around the water jackets and corners of the intake manifold. It is also important to follow the manufacturer's torque specifications when tightening the manifold to prevent leaks.

By using a valley pan gasket, you can maintain a clean and efficient engine, preventing oil from reaching the intake manifold and keeping the manifold temperature under control.

The Weiand Stealth intake manifold may not need a valley pan gasket because it is made from aluminium

A valley pan gasket is designed to prevent oil from baking underneath the manifold, especially around the exhaust crossover area. If the intake manifold and cylinder heads have an exhaust crossover passage, it is recommended to use a valley pan gasket. However, if the exhaust crossover passage is blocked off, as is often the case with aftermarket aluminium intake manifolds, a valley pan gasket may not be necessary. This is because there is no additional source of heat, and the aluminium construction of the Weiand Stealth intake manifold further reduces the need for a gasket to manage heat.

It is worth noting that some intake manifold manufacturers, including Weiand Stealth, instruct users not to use a valley pan gasket. This is likely due to the aluminium construction of the manifold, which conducts heat differently from cast iron manifolds. Aluminium conducts heat more efficiently than cast iron, so an aluminium intake manifold may not require additional measures to manage heat, such as a valley pan gasket.

However, it is always a good idea to refer to the manufacturer's instructions and recommendations when installing an intake manifold. It is also important to ensure proper sealing of the intake ports and water jackets with high-temperature silicone to prevent leaks.

The valley pan gasket is not necessary if the exhaust crossover passage is blocked off

The exhaust crossover passage is a separate port that is primarily used for cold engine driveability and emissions. It circulates hot exhaust gas through a passage in the intake manifold to heat the intake and improve cold-weather drivability. However, the exhaust crossover passage can be blocked off, especially in performance applications, to prevent the intake manifold from getting too hot, which can cause fuel percolation and vapor lock issues.

When blocking off the exhaust crossover passage, it is recommended to use a thin piece of stainless steel sheet metal cut larger than the intake gasket hole. This sheet metal should be placed between the cylinder head and the intake gasket, with a layer of high-temperature RTV silicone applied to both sides to ensure a proper seal.

It is important to note that some intake manifold manufacturers, such as Weiand Stealth, instruct users not to use a valley pan gasket with their products. Therefore, if you are using an intake manifold that does not have an exhaust crossover passage or if you are blocking off the passage, you do not need to use a valley pan gasket.

The valley pan gasket is not necessary if an aftermarket aluminium intake manifold is used

The valley pan gasket is designed to be used in conjunction with a cast iron intake manifold. The gasket acts as an oil barrier, preventing oil from splashing onto the bottom of the manifold and causing issues such as fuel percolation and vapor lock. However, with an aluminium intake manifold, the risk of these issues occurring is significantly reduced due to the lower heat conduction of aluminium compared to cast iron.

It is worth noting that some users have reported success in using the valley pan gasket with an aluminium intake manifold by cutting the intake gasket off of the valley pan and using separate paper gaskets. This method may be useful if you want to err on the side of caution or if you are using an aluminium intake manifold with a particularly high heat output.

Additionally, it is important to consider the type of cylinder heads you are using. If your cylinder heads have an exhaust crossover passage, you may need to use a valley pan gasket to prevent oil from leaking into the passage. However, if you are using an aftermarket aluminium intake manifold, you can block off the exhaust crossover passage, eliminating the need for a valley pan gasket.

In conclusion, while the use of a valley pan gasket may be recommended for certain configurations, it is not necessary when using an aftermarket aluminium intake manifold. The decision to use a valley pan gasket should be based on the specific components of your engine and the instructions provided by the manufacturer.
