Building a pan car can be a complex and time-consuming process, but it can be a rewarding experience for enthusiasts. The first step is to decide on the design and gather the necessary components, which may include a front end, centre shock, rear pod, axle, diff unit, and a plate chassis. Some builders choose to purchase a kit, while others opt for scratch-building, using techniques like 3D printing or laser cutting. The construction process involves assembling the various parts, such as the motor, gears, axles, and steering linkages. Customization is also possible, with adjustments to the rear pod, suspension, and tyre choices. Painting, detailing, and adding decals are the final steps before the car is ready for racing or display.
| Characteristics | Values |
|---|---|
| Main Components | Front end, centre shock, rear pod, axle and diff unit, and a plate chassis |
| Steering Mechanism | Tie rods connecting the servo to the wheels |
| Motor | Attached to a motor mount with a pinion gear meshed with the spur gear on the axle |
| Spur Gear | Central component of the ball differential assembly |
| Chassis Material | Laser-cut acrylic or 3D-printed carbon fiber or acrylic |
| Rear Pod | Adjustable, 3D-printed, with a dual shock absorber setup |
| Tires | Choice matters; use spool and gear for carpet, ball diff for street |
| Suspension | Easier to work with using a damper tube like the Schumacher |
| Belly Pan | Custom-built using a fiberglass mold and carbon fiber |
