Harley Davidson motorcycle enthusiasts often use terms like panhead and shovelhead to refer to certain types of engines. While it is possible to put a panhead on a lower shovelhead motor, there are some modifications that need to be made. For example, the oiling system is different for the heads, and the pushrod tubes and rocker boxes may need adjustments. Some people opt to build a panhead from scratch, while others experiment with mixing and matching parts.
Explore related products
What You'll Learn
It is possible to fit a panhead on a lower shovel head motor
One of the primary challenges is related to the oiling system. Shovelheads typically use external oil lines, while pre-1965 panheads oiled up the pushrod tubes. This difference in oiling systems can create complications that need to be carefully addressed during the modification process.
Another consideration is the rocker arm ratio. Shovelheads have a rocker arm ratio of 1.5:1, while pans have a ratio of 1.6:1. This discrepancy can lead to issues with valve interference during overlap due to the longer rocker arms on the panheads. Some builders have suggested using STD panheads, which employ shovel bolt patterns and intakes, to overcome this challenge.
Additionally, there may be issues with the head bolts not lining up correctly. It might be necessary to plug and tap one or two bolts to ensure proper alignment. This issue has been reported by some builders, but others have successfully completed the modification without encountering this problem.
When undertaking this modification, it is advisable to seek out aftermarket panheads specifically designed for shovel heads, such as those offered by S&S. These aftermarket parts can simplify the process by ensuring compatibility between the panhead and shovel head components.
In conclusion, while it is possible to fit a panhead on a lower shovel head motor, it requires careful consideration of the oiling system, rocker arm ratios, and potential bolt alignment issues. With the right approach and parts, a smooth-running engine can be achieved, as evidenced by the experiences of other motorcycle enthusiasts who have successfully undertaken this unique modification.
