Cody Casey
Autodesk Fusion 360 is a CAD program that allows users to pan, zoom, and orbit their 3D models. The default settings for these functions are to use the middle mouse button to pan and orbit the view, while the Ctrl + Shift + middle mouse button shortcut is used for zooming. However, Fusion 360 allows users to customize their orbit and pan settings, which can be helpful when transitioning from other CAD tools like Solidworks or Tinkercad. Users can change these settings by accessing the Preferences menu and selecting their preferred shortcuts under Pan, Zoom, Orbit Shortcuts.
| Characteristics | Values |
|---|---|
| Default controls | Can be learned quickly and become second nature |
| Middle mouse button | Used to pan and orbit the view |
| Trackpad | Most do not have a middle mouse button, so a mouse is required |
| F2, F3, and F4 keys | Can be used to pan, zoom, and orbit the view without the middle mouse button |
| Preferences | Can be accessed by clicking on the user profile in the top right corner and selecting "Preferences" under "General" |
| Shortcut settings | Can be customized under "Pan, Zoom, Orbit Shortcuts" in the Preferences menu |
| SolidWorks transition | Users coming from SolidWorks can retain their mannerisms by selecting SolidWorks in the Preferences menu |
| Zoom | Can be achieved by rolling the middle mouse button or using Ctrl + Shift + middle mouse button |
| Zoom to box | Ctrl + Shift + middle mouse button (Windows) or Command + Shift + middle mouse button (MacOS) |
| Double-click | Double-clicking the mouse wheel button will "zoom to fit" the model on the screen |
Explore related products
$15.12 $29.99
What You'll Learn
Panning with a mouse in Fusion 360
Panning in Fusion 360 allows you to navigate your model or design by moving it up, down, left, or right. To pan with a mouse in Fusion 360, you typically need to use the middle mouse button. Simply hold down the middle mouse button and drag the mouse in the desired direction to pan the view.
It is worth noting that the specific mouse controls for panning and orbiting in Fusion 360 may vary depending on your previous CAD tool preferences. By default, Fusion 360 uses the middle mouse button for panning. However, if you are transitioning from another CAD program, such as SolidWorks or Inventor, you can customize your orbit and pan settings.
To customize your settings, go to the Preferences menu by clicking on your profile in the top right corner of the dashboard. Under the General tab, you will find the Pan, Zoom, and Orbit shortcuts options. From the drop-down menu, you can select your previous CAD tool, such as SolidWorks or Inventor, to retain the mouse gestures you are familiar with.
For example, if you are transitioning from SolidWorks, you can hold Control and the middle mouse button to pan in Fusion 360, similar to SolidWorks. Additionally, you can use the Shift and middle mouse button combination to rotate or orbit the model in Fusion 360, which differs from SolidWorks.
It is important to note that laptop trackpads typically lack a middle mouse button. In such cases, Fusion 360 offers an alternative by allowing you to use the F2, F3, and F4 keys to pan, zoom, and orbit the view without the need for a middle mouse button.
Pan-Seared Crappie Perfection
You may want to see also
Explore related products
Zooming with a mouse
To zoom in Fusion 360, you can use the middle mouse button or a combination of Ctrl + Shift + the middle mouse button. This is different from SolidWorks, where users hold the Control key with the middle mouse button to pan and hold the mouse wheel to orbit.
If you are used to SolidWorks, you can retain these controls in Fusion 360 by adjusting the settings. Go to Preferences > General, where you will find the pan, zoom, and orbit shortcuts.
To zoom to a specific area in Fusion 360, use the "zoom to box" feature with Ctrl + Shift + the middle mouse button on Windows or Command + Shift + the middle mouse button on MacOS. If you ever lose your model, double-clicking the mouse wheel button will "zoom to fit."
It is worth noting that the PowerMill preset uses its own default orbit type, which differs from the standard Fusion 360 controls.
Pan-Seared Broccoli: A Quick, Tasty Side
You may want to see also
Explore related products
$159.95
Using the middle mouse button to orbit
To orbit in Fusion 360, you typically use the middle mouse button. This is the default setting for orbiting in the program, and it is in line with most other CAD programs.
If you are using a mouse with Fusion 360, you can simply press down on the middle mouse button and drag your mouse to orbit around your model. This is a quick and intuitive way to navigate your 3D space.
However, if you are using a laptop trackpad, you may not have access to a middle mouse button. In this case, you can still use Fusion 360's settings to control orbiting without a mouse. To do this, go to the top right corner of the dashboard and click on your profile. From the drop-down menu, select "Preferences", then "General", and choose the ""Inventor" option under "Pan, Orbit, and Zoom Shortcuts". This will allow you to use the F2, F3, and F4 keys to pan, zoom, and orbit, respectively.
It is worth noting that you can also customize your orbit settings in Fusion 360 to match those of other CAD tools you may be familiar with, such as Solidworks or Tinkercad. This can be done through the "Preferences" menu, under "Pan, Zoom, Orbit Shortcuts".
Caraway Cookware: Oven-Safe?
You may want to see also
Explore related products
Customising orbit and pan settings
Autodesk Fusion allows you to customise your orbit and pan settings to make your transition from other CAD tools easier. To do this, first, go to the dashboard and click on your name in the upper right-hand corner. From the drop-down menu, select 'Preferences'.
From the 'Preferences' menu, on the main 'General' screen, select the drop-down menu from 'Pan, Zoom, Orbit Shortcuts'. From this drop-down, you have several program choices. The default will be 'Fusion'. You can also select from the other options, including Inventor, Solidworks, Alias, and Tinkercad.
If you are using a laptop without a middle mouse button, you can still customise the settings. Fusion 360 has a setting that allows you to use the F2, F3, and F4 keys to pan, zoom, and orbit the view without the middle mouse button. To do this, click on your profile in the top right and go to 'Preferences'. Under 'General', select "Inventor" Pan, Orbit, and Zoom shortcuts.
If you are transitioning from another CAD tool, customising your orbit and pan settings can make your transition easier. You can use the pan, zoom, and orbit controls from your past software (like SolidWorks or Inventor) instead of the default Fusion settings.
How JB Weld Can Permanently Seal Oil Pan Leaks
You may want to see also
Explore related products
Using keyboard shortcuts to pan, zoom and orbit
Autodesk Fusion 360 allows you to customise your orbit, pan and zoom settings to make your transition from other products, such as Solidworks, Tinkercad and OnShape, easier.
To do this, go to the top right corner of the dashboard and click on your name in the drop-down menu, select 'Preferences', then ''General' on the main screen, and finally, select the drop-down menu from 'Pan, Zoom, Orbit Shortcuts'. From here, you can select from several program choices, including the default 'Fusion', as well as ''Inventor', 'Solidworks', 'Alias', and 'Tinkercad'.
While the default settings can be changed, it is worth noting that the default Fusion controls will soon become second nature if you choose to learn them.
If you are using a Mac, the middle mouse button does not work for panning or orbiting, only for zooming in and out. However, you can use the F2, F3, and F4 keys to pan, zoom, and orbit the view without the middle mouse button.
Additionally, you can switch workspaces with Ctrl+[ and Ctrl+] key combinations.
Cleaning Cast Iron: Cornbread Pan Care
You may want to see also
Frequently asked questions
To pan, simply hold the middle mouse button. To orbit, hold Shift and the middle mouse button.
To change the settings, go to Preferences in the drop-down menu under your profile in the top right corner of the dashboard. From the Preferences menu, select the General screen and choose from the Pan, Zoom, Orbit Shortcuts drop-down menu. You can select from options including Inventor, Solidworks, Alias, and Tinkercad.
Yes, if you're using a trackpad without a middle mouse button, you can use the F2, F3, and F4 keys to pan, zoom, and orbit the view. To enable this setting, go to Preferences and select "Inventor" Pan, Orbit, and Zoom shortcuts under General.
