Unscrewing The Haley Pan Head: Removing The Head Cover

how to remove head cover on a haley pan head

The Harley-Davidson Panhead engine is an iconic motorcycle engine produced from 1948 to 1965. Its nickname comes from the rocker covers, which resemble cooking pans. This engine replaced the Knucklehead engine and was, in turn, replaced by the Shovelhead engine. The Panhead engine was a significant improvement over its predecessor, addressing issues of heat dissipation and oil leaks. In this article, we will discuss the process of removing the head cover on a Harley-Davidson Panhead engine, including the tools required and the steps to take.

Characteristics Values
Outer primary cover removal Drain primary fluid, remove the plug underneath the primary, remove shift arm linkage, loosen clutch cable, remove derby cover and primary chain inspection cover, remove clutch release assembly, detach clutch cable from release assembly, loosen primary chain tensioner, remove primary cover
Cam/gear cover removal Remove generator, use a hammer handle or broom handle to gently tap inner face of cam cover, work putty knife or similar tool around to break away gasket, carefully wiggle and slide cover off
Primary cover bolt removal Use bolt extractor tool purchased from hardware store or Amazon

cycookery

Remove the battery negative cable, fuel tank, and exhaust

To remove the battery negative cable, fuel tank, and exhaust on a Harley Panhead, follow these steps:

Begin by removing the battery negative cable. This is an important first step to avoid any electrical issues or safety hazards when working with fuel. Ensure the bike is switched off and secure, and then locate the battery. The negative cable is usually black and can be disconnected by carefully loosening or unscrewing it from the battery terminal.

Next, you'll want to remove the fuel tank. This process can vary slightly depending on the year and model of your Harley Panhead, but the basic steps are as follows:

  • Start with a nearly empty fuel tank if possible. If not, you will need to drain the fuel into an appropriate container.
  • Remove the front and rear fasteners holding the console assembly to the tank.
  • Open the fuel door, remove the filler cap, and place a soft towel on the rear fender to protect the finish.
  • Depending on your model, there may be additional Hex (Allen) screws under the fuel door that need to be removed.
  • Disconnect the pump wiring harness plug and the fuel level sensor plug on the left underside of the tank.
  • Disconnect the hard vent line and the fuel supply line. You may need a funnel and a hose to catch any remaining fuel.
  • For fuel-injected models with a five-gallon fuel tank, disconnect the crossover fuel line at the front of the tank.
  • Remove the rubber tank mount caps to access the mounting fasteners.
  • Using a suitable tool, such as a 1/2" socket or T40 Torx driver, remove the front and rear tank mounting fasteners.
  • With all connections and fasteners removed, gently lift the fuel tank from the bike and set it aside in a safe place.

Now, you can move on to removing the exhaust. This process can vary significantly depending on your specific model, but here are some general steps:

  • Refer to your Harley Panhead's service manual for specific instructions on removing the exhaust.
  • Ensure you have a clean and safe area to work in, as this process can be labor-intensive and require multiple days.
  • Remove the top motor mount, including the horn assembly, and any other components that may be in the way, such as the fuel line and engine temp sensor.
  • Carefully detach any sensor plugs and throttle cables, labelling them for easy reassembly.
  • Remove the hardware securing the throttle body to the heads and gently slide it away from the motor.
  • If needed, remove the coil mount and coil to create more space for the next steps. Ensure you label the wires and coils for reassembly.
  • Loosen and remove the upper rocker box, and then remove the spark plugs.
  • Raise the rear wheel and shift the motorcycle into high gear. Spin the rear wheel until you reach top dead center, reducing pressure on the pushrods.
  • Remove the pushrod clips and then loosen and remove the breather assembly and rocker arm towers. Label and set aside these components.
  • With the above steps completed, you can now remove the exhaust system. Again, the exact process will depend on your specific model, so refer to your service manual for detailed instructions.

Remember to work methodically and safely, and always refer to your service manual for detailed instructions specific to your Harley Panhead model.
