Removing Panhard Bar From Jeep: A Step-By-Step Guide

Removing the pan hard bar from a Jeep Wrangler can be a tricky task, but with the right tools and guidance, it is doable. The pan hard bar, also known as the track bar, is a vital component of a Jeep's suspension, connecting the axle to the frame and controlling the axle's movement. While removing it may improve the ride quality, it is essential to consider the potential consequences. Removing the pan hard bar can affect the Jeep's handling and stability, especially on the road. It is recommended to test drive the Jeep after removing the rear pan hard bar to see if the change aligns with your preferences. If you decide to proceed with the removal, ensure you have the necessary tools and safety measures in place. Always consult a professional mechanic or a trusted Jeep forum for detailed instructions and safety precautions specific to your Jeep model.

Removing the rear pan hard bar can improve the ride

The Panhard bar, also known as a Panhard rod, track rod, or track bar, is a stabilising unit designed to reduce the side-to-side roll of a vehicle. It is bolted to the rear axle and the frame of the vehicle, and it works by restricting the left-to-right movement of the rear axle, allowing the rear wheels to move up and down. This helps to keep the wheels aligned with the driveshaft and centre of the vehicle, reducing the "rear steer" effect, which is when the rear wheels are not pointed straight, causing the vehicle to feel loose and unsteady during hard acceleration or cornering.

Removing the rear Panhard bar can improve the ride of your Jeep by providing more flexibility and a smoother driving experience. Without the Panhard bar, the rear axle will have more lateral movement, which can be beneficial for off-roading or driving on uneven surfaces. The increased flexibility can also help with traction and improve launching abilities.

However, it is important to note that removing the Panhard bar may also reduce the stability of your Jeep, especially during hard acceleration or cornering. If you decide to remove the rear Panhard bar, it is recommended to replace it with an alternative stabilising system, such as a Watts linkage, which offers similar functionality with improved symmetry and reduced lateral movement.

Additionally, if you plan to change the ride height of your Jeep, it is essential to install an adjustable Panhard bar. This will allow you to alter the suspension geometry and ensure the rear axle remains centred with the driveshaft and transmission, maintaining the proper balance of the factory geometry.

In conclusion, removing the rear Panhard bar can have both benefits and drawbacks. It can improve ride flexibility and traction but may reduce stability during certain driving conditions. If you choose to remove the Panhard bar, consider installing an alternative stabilising system and ensure that you have the proper suspension geometry for your desired ride height.

Removing the front pan hard bar may also improve the ride

The Panhard bar is an essential component for keeping your Jeep's rear axle stable and preventing it from shifting during turns. However, removing the front Panhard bar can offer some benefits, including a potential improvement in ride quality.

The Panhard bar connects the chassis to the rear axle, and its primary function is to limit the axle's side-to-side movement. This stabilises the axle and improves driveshaft alignment. While this is beneficial for handling and cornering, the Panhard bar can also transmit some harshness from the road into the cabin, affecting the ride quality.

By removing the front Panhard bar, you may notice a smoother ride, particularly on uneven surfaces. This is because the Panhard bar can restrict the axle's vertical movement, and its removal allows for more suspension travel. As a result, the tyres can better absorb bumps and dips in the road, leading to a more comfortable ride.

Additionally, the removal of the front Panhard bar can provide more clearance for larger tyres or suspension modifications. This is especially beneficial for off-roading, where the increased suspension travel can help navigate rough terrain.

However, it is important to note that removing the front Panhard bar can affect handling and cornering stability. The Panhard bar plays a crucial role in keeping the axle centred, and its removal can lead to increased lateral axle movement, impacting the vehicle's responsiveness and predictability during turns.

Therefore, if you plan to remove the front Panhard bar, it is generally recommended for off-road use or situations where ride quality is a higher priority than handling performance. For optimal handling, especially on the track, it is advisable to retain the Panhard bar or consider upgrading to an adjustable variant.

Removing both can be done to see if you can live without them

Removing both the track bar and the panhard bar can be done to see if you can live without them. The panhard bar, or track bar, is a vital component of your Jeep's suspension system. Its purpose is to keep track of the relation between the Jeep's body and its axle assemblies. It has two attachment points, one on the Jeep's frame/body and the other on the axle assembly, connected by a link, which is the track bar.

Track bars are designed to prevent unwanted lateral movement of the axle assemblies. Without them, you would feel the body float severely left or right when turning, which would likely lead to a severe accident. They are essential for off-road driving, as without them, it would be impossible to traverse any type of off-road terrain.

However, some Jeep enthusiasts choose to remove both the front and rear track bars for a smoother ride. This is because the track bars can cause a jarring, stiff, or harsh ride. Removing them allows for more axle flex and a smoother, more comfortable driving experience. It is also beneficial for off-roading, as it allows for better articulation and increased control when moving across lumps and gaps.

If you are considering removing both track bars, it is important to note that this modification is only suitable for leaf-sprung vehicles. Additionally, you may need to make adjustments to your suspension to compensate for the removal of the track bars. This may include getting a shorter shackle lift and ensuring your pinion angle is correct.

Removing both track bars can be a good way to see if you can live without them and improve your Jeep's performance, both on and off-road. However, it is important to exercise caution and ensure you have the correct setup for your vehicle.

A triangulated 4-link front with no pan hard bar can cause issues with bump steer

A triangulated 4-link suspension setup is designed so that the axle moves straight up and down, without the need for a track bar. However, this can lead to issues with bump steer. Bump steer occurs when the axle travels in an arc, causing the drag link to push the knuckle or pitman arm, which results in steering induced by a bump. This can be a problem with a 4-link suspension because of the vertical motion.

In a triangulated 4-link setup, the upper bars are angled relative to the vehicle centreline, forming a triangle that keeps the rear axle centred. This differs from a parallel 4-link setup, which uses a Panhard bar or another device to locate the axle laterally.

While a Panhard bar can be added to a triangulated 4-link setup to address bump steer, it will bind up severely with even a few inches of travel and is likely to rip a bracket from the frame. This is because the triangulated 4-link is designed for purely vertical axle movement, with no side-to-side motion.

Some alternatives to a Panhard bar in addressing bump steer include full hydraulic steering, rack and pinion steering, hydraulic-assist steering, and drive-by-wire or drive-by-cable steering. However, each of these options has its own drawbacks and may not be ideal for a daily driver.

One possible solution to the bump steer issue in a triangulated 4-link setup is to use a dropped pitman arm or another method to make the drag link horizontal at ride height. This can help reduce the amount of bump steer and improve the streetability of the vehicle.

A removable Panhard bar may bind up severely at just a few inches of travel

A Panhard bar, also known as a Panhard rod, track rod, or track bar, is a stabilising unit designed to reduce the side-to-side roll of a vehicle. It connects diagonally from the axle to the frame of the vehicle, allowing the rear wheels to move up and down but not laterally (left to right). This keeps the body of the car centred over the axle and reduces "rear steer".

For example, on a suspension with a 30-inch Panhard bar and 10 inches of total wheel travel, the axle would move less than 0.21 inches off-centre at its extremes. This movement goes down to 0.155 inches with a 40-inch Panhard bar with the same 10 inches of travel.

When lowering a car, the Panhard bar swings in an arc, pushing the entire rear axle to one side of the vehicle. To compensate, the bar needs to be adjusted to a shorter length to re-centre the axle. This is why it is recommended to get an adjustable Panhard bar when making any change in ride height.

A Panhard bar is a simple and lightweight solution to stabilising the rear axle of a vehicle. However, if it is not very long (i.e. more parallel to the ground), the excess movement can throw off handling. An alternative system is the Watts linkage, which uses four points of connection for better symmetry but is more complex, heavier, and more expensive.
