B Series Oil Pan Gasket Compatibility: Are They Interchangeable?

The Honda and Acura B-Series inline-4 engines were used in many Honda and Acura applications between 1989 and 2001. Available in 1.6L, 1.7L, 1.8L and 2.0L displacements, this family of Dual Overhead Cam (DOHC) engines was the first to feature Honda’s VTEC variable valve timing system. As with any engine, leaks can develop over time and the oil pan gasket is a common leak found on the B-series engines.

The Honda and Acura B-Series inline-4 engines were used in many vehicles

The B-Series engines were introduced as a performance option alongside the more economical D-series engines. They featured dual overhead cams, high-pressure die-cast aluminium blocks, and cast-in quadruple-Siamese iron liners. The basic design of the B-Series engines remained consistent, with only minor upgrades differentiating the various models.

The B-Series family included both DOHC and SOHC engines, with the B16, B18, and B20B being the most notable variants. The B16, in particular, the B16B, was highly sought after for its impressive power output and high-revving capabilities. The B18C, found in the JDM Integra Type-R, is often considered the "holy grail" of B-Series engines for its exceptional power output.

The B-Series engines were replaced by the K-Series in Civic, Integra, Odyssey, and CR-V applications. However, their popularity has endured, and they continue to be a favourite among tuning enthusiasts. The B-Series engines are known for their tuning potential, with stock engines capable of producing impressive horsepower figures and even higher outputs with modifications.

The B-Series engines had some issues with oil pan gasket leaks, which could be exacerbated by tightening the oil pan bolts beyond the original torque specification. This would crush the raised dimples on the oil pan, designed to prevent over-compression of the gasket, leading to worse leaks.

The oil pan gasket is a common leak found on the B-series engines

The Honda and Acura B-Series inline-4 engines were used in many Honda and Acura applications between 1989 and 2001. Available in 1.6L, 1.7L, 1.8L and 2.0L displacements, this family of Dual Overhead Cam (DOHC) engines was the first to feature Honda’s VTEC variable valve timing system. They are reliable and are found in many vehicles that are still on the roads today, along with being a popular engine swap option for performance enthusiasts.

As with any engine, leaks can develop over time and with use. The oil pan gasket is a common leak found on the B-Series engines. Many owners or shops may try to tighten the oil pan bolts to stop the leak. However, this makes the problem worse. The oil pan on these engines has raised dimples that are stamped in the flange to prevent over-compression of the gasket on the assembly line. By tightening the bolts beyond the original torque specification, these dimples can be crushed, and the oil pan sealing flange can deform, creating leak paths that worsen the problem.

The solution is to replace the problematic gasket with a new one designed to prevent over-compression of the gasket and over-torquing of the oil pan bolts. The Fel-Pro PermaDryPlus oil pan gasket is a recommended option. It features a rigid, steel-core construction and built-in torque limiters that help eliminate overtightening and gasket splitting. It also has a proprietary moulded rubber design that helps eliminate leak paths, especially in problem corner areas. Its one-piece construction is easier to install than multi-piece assemblies and helps reduce the potential for installation errors.

When removing the old gasket, it is important to remove the two compression limiters moulded into it, which can be found only on the transmission side of the pan. If these limiters are left in place, the new gasket will stack on top of them and result in an oil leak. Be sure to inspect and remove them when cleaning the flanges. The new gasket should be installed on a clean and dry sealing surface, with no sealers, adhesives, or RTV applied to the gasket. However, there are four places on the engine block where RTV must be applied as a supplemental sealer: the two joints on the block created by the oil pump and the two joints created by the RMB retainer.

Technicians may try to tighten the oil pan bolts to stop the leak, but this makes matters worse

The Honda and Acura B-Series inline-4 engines were used in many Honda and Acura applications between 1989 and 2001. Available in 1.6L, 1.7L, 1.8L and 2.0L displacements, this engine series was the first to feature Honda’s VTEC variable valve timing system. As with any engine, leaks can develop over time and the oil pan gasket is a common leak found on the B-Series engines.

The oil pan sealing flange can deform, creating leak paths and resulting in an even worse leak. At this point, the OE-style oil pan gasket design will no longer work, because it relies on the correctly formed dimples to prevent over-compression of the gasket.

The solution is to replace the problematic gasket with a new one that features a rigid, steel-core construction and built-in torque limiters. This will prevent over-compression of the gasket and over-tightening of the oil pan bolts, even in cases where the flange dimples have been deformed.

It is important to note that tightening the oil pan bolts on pans with cork gaskets can sometimes be done gently to mitigate an oil pan leak. However, in the case of B-Series engines, this is not recommended due to the presence of the raised dimples on the oil pan.

The Fel-Pro PermaDryPlus oil pan gasket features a rigid, steel-core construction and built-in torque limiters

The Fel-Pro PermaDryPlus oil pan gasket is a welcome solution to the common problem of oil pan leaks in Honda B-Series engines. These engines, which were used in Honda and Acura applications between 1989 and 2001, are known to develop leaks over time, particularly in the oil pan gasket.

The oil pan gasket is a critical component that can be damaged by overtightening the oil pan bolts. This is a common issue, as it is a typical response to a leak. However, the oil pans in these engines have raised dimples designed to prevent over-compression of the gasket during assembly. When these dimples are crushed by overtightening, they can deform, creating leak paths that worsen the problem.

The Fel-Pro PermaDryPlus oil pan gasket offers a much-needed solution to this issue. Unlike the OE-style gaskets, it features a rigid, steel-core construction with built-in torque limiters. This innovative design prevents over-compression of the gasket and over-torquing of the oil pan bolts, even if the flange dimples have been deformed. The gasket's rigid carrier ensures durability, perfect alignment, and an instant fit.

The gasket also incorporates Fel-Pro's proprietary molded rubber formulation, with dual sealing beads on each side of the steel core, providing exceptional sealing performance. The one-piece construction simplifies the installation process compared to multi-piece assemblies, reducing the potential for installation errors. Additionally, the included Oil Pan SnapUps® hold the gasket in place, further streamlining the installation process.

The Fel-Pro PermaDryPlus oil pan gasket is an ideal aftermarket solution for Honda B-series engines, offering superior sealing performance and ease of installation. It is well-suited for high-performance and turbocharged applications, effectively handling higher oil temperatures and crankcase pressures.

The OE gasket has two compression limiters that can be found on the transmission side of the pan

The OE gasket's compression limiters play a vital role in maintaining the integrity of the gasket and preventing oil leaks. By understanding their location and function, technicians can effectively address oil pan gasket leaks in Honda B-Series engines. This knowledge also highlights the importance of proper gasket maintenance and replacement, ensuring the optimal performance of the vehicle's engine.

The Fel-Pro PermaDryPlus B-Series Oil Pan Gasket Set offers an innovative solution to common oil pan gasket leaks in Honda and Acura B-Series engines. Unlike the OE-style gaskets, the Fel-Pro gasket features a rigid, steel-core construction and built-in torque limiters. This design prevents over-compression of the gasket and over-torquing of the oil pan bolts, even if the flange dimples have been deformed. The proprietary molded rubber formulation and precisely located dual sealing beads on each side of the steel core provide exceptional sealing performance.

The installation process for the Fel-Pro PermaDryPlus gasket is straightforward. It must be installed on clean and dry sealing surfaces, with no sealers, adhesives, or RTV applied to the gasket. However, it is important to follow the manufacturer's recommendations for RTV application in specific areas of the engine block to ensure a reliable seal. The included Fel-Pro oil pan Snap-Ups® further simplify the installation process, making it easier and faster for technicians.

In summary, the OE gasket's two compression limiters found on the transmission side of the pan are crucial in preventing oil leaks. The Fel-Pro PermaDryPlus gasket offers a superior alternative to the OE-style gasket, ensuring effective sealing and preventing common issues associated with over-tightening and gasket deformation in Honda B-Series engines.
